Brembo 09.B969.11 UV Coated Rear Brake Rotor for Audi S4, S5, A6, A7, Q5/Porsche

Regular price: $82.95
Regular price
Sale price: $82.95

Shipping calculated at checkout.

In Stock: 695

Orders by 1pm PST ship same business day

Free Shipping w/3-4 Day Delivery

Authorized Dealer

Fitment Guarantee

30-Day Hassle Free Returns

Product Specification:

SKU:BRE09.B969.11

MPN: 09.B969.11

UPC: 8020584218396

Weight: 18.0 lb

Inventory: 695

Type: Brake Rotors - OE

Description

Vehicle Fitment

Audi A4 / A4 allroad (B9)
2017-2018 Audi A4 Quattro (B9) - 2.0L TFSI I4
2017-2022 Audi A4 allroad Quattro (B9) - 2.0L TFSI I4
Audi A5 / A5 Sportback (B9)
2018-2022 Audi A5 Quattro (B9) - 2.0L TFSI I4
2018-2022 Audi A5 Sportback Quattro (B9) - 2.0L TFSI I4
Audi S4 (B8/B8.5/B9)
2011-2016 Audi S4 (B8/B8.5) - 3.0L TFSI Supercharged V6
2018-2023 Audi S4 (B9) - 3.0L TFSI Turbo V6
Audi S5 / S5 Sportback (B8/B8.5/B9)
2011-2017 Audi S5 (B8/B8.5) - 3.0L TFSI Supercharged V6
2018-2023 Audi S5 / S5 Sportback (B9) - 3.0L TFSI Turbo V6
Audi A6 / A6 allroad (C7/C8)
2014-2018 Audi A6 / A6 Quattro (C7) - 2.0L/3.0L TFSI
2019-2022 Audi A6 Quattro (C8) - 3.0L TFSI Turbo V6
2020-2022 Audi A6 allroad Quattro (C8) - 3.0L TFSI Turbo V6
Audi A7 / A7 Sportback (C7/C8)
2012-2018 Audi A7 Quattro (C7) - 3.0L TFSI Supercharged V6
2019-2022 Audi A7 Sportback Quattro (C8) - 3.0L TFSI Turbo V6
Audi A8 (D4)
2013-2014 Audi A8 Quattro (D4) - 3.0L TFSI Supercharged V6
Audi Q5 / Q5 Sportback (8R/FY)
2013-2017 Audi Q5 (8R) - 2.0L/3.0L TFSI
2018-2022 Audi Q5 / Q5 PHEV (FY) - 2.0L TFSI I4
2021-2022 Audi Q5 Sportback (FY) - 2.0L TFSI I4
Audi SQ5 (8R/FY)
2014-2017 Audi SQ5 (8R) - 3.0L TFSI Supercharged V6
2018-2023 Audi SQ5 (FY) - 3.0L TFSI Turbo V6
2021-2022 Audi SQ5 Sportback (FY) - 3.0L TFSI Turbo V6
Audi ActiveHybrid 3 (C7)
2013-2015 Audi A6 Hybrid (C7) - 2.0L TFSI Hybrid
Porsche Macan (95B)
2015-2022 Porsche Macan (95B) - 2.0L Turbo I4 / 3.0L Twin Turbo V6

Fitment Notes

Rear axle rotor; sold individually
Verify rear rotor diameter is 330mm before ordering; some trim levels and brake packages use different sizes
Audi OE cross-reference: 4H0615601D, 4H0615601H, 4H0615601K, 4H0615601Q
Matching front rotor for B8/B8.5 S4/S5 and 8R Q5/SQ5: Brembo 09.B970.11 (345x30mm)
Front rotor varies by model and generation; verify front rotor part number separately for C7 A6/A7 and B9 applications
Recommended Brembo rear brake pads: NAO Ceramic or Low-Met formulation (verify by application)
Includes fixing screw for installation

Features

Brembo PRIME UV Coated OE-equivalent replacement rear rotor
High-carbon cast iron construction for reduced noise and vibration
Brembo Pillar Venting Technology (PVT) for up to 40% greater thermal crack resistance
Full UV coating on braking surfaces, hub, and internal ventilation chambers
Environmentally friendly solvent-free UV coating process
Electronic balancing for minimal runout and vibration
Intelligent part number and minimum thickness marking on rotor
Precision-manufactured to meet or exceed OE specifications

Specifications

Position: Rear
Rotor diameter: 330mm (12.99")
Rotor thickness (nominal): 22mm
Minimum thickness: 20mm (0.790")
Overall height: 36mm (1.42")
Center bore: 68mm (2.68")
Bolt holes: 5
Bolt pattern: 5x112mm
Rotor type: Vented
Rotor surface: Solid (smooth/plain)
Material: High-carbon cast iron
Coating: Brembo UV protective coating
Venting: Pillar Venting Technology (PVT)
Sold individually

Included Components

Brembo PRIME UV Coated rear brake rotor (1)
Fixing screw hardware kit

Product Description

The Brembo 09.B969.11 is a PRIME UV Coated rear brake rotor engineered as a direct OE-equivalent replacement for a wide range of Audi and Porsche vehicles. This 330mm vented rotor is constructed from high-carbon cast iron to minimize noise and vibration while delivering consistent braking performance. Brembo's patented Pillar Venting Technology uses uniquely shaped internal pillars instead of conventional vanes, increasing airflow through the rotor and providing up to 40% greater resistance to thermal cracking. The full UV coating protects all rotor surfaces including the hub and internal ventilation chambers against corrosion, maintaining a clean appearance and extending service life. Each rotor is electronically balanced and precision-manufactured to tight tolerances for smooth, vibration-free braking right out of the box. A fixing screw hardware kit is included for simple installation.
