Brembo 09.C820.11 UV Coated Front Rotor for 18-24 Land Rover Defender/Discovery

Vehicle Fitment

• 2021-2024 Land Rover Defender 90 (S, SE, X-Dynamic SE, HSE, X-Dynamic HSE, X, V8, 2.0L I4 Turbo P300 / 3.0L I6 Mild Hybrid P400 / 5.0L V8 Supercharged P525, AWD)
• 2021-2024 Land Rover Defender 110 (S, SE, X-Dynamic SE, HSE, X-Dynamic HSE, X, V8, 2.0L I4 Turbo P300 / 3.0L I6 Mild Hybrid P400 / 5.0L V8 Supercharged P525, AWD)
• 2023-2024 Land Rover Defender 130 (S, SE, X-Dynamic SE, HSE, X-Dynamic HSE, X, 3.0L I6 Mild Hybrid P400, AWD)
• 2018-2019, 2021-2024 Land Rover Discovery (S, SE, HSE, HSE Luxury, R-Dynamic SE, R-Dynamic HSE, 2.0L I4 Turbo / 3.0L V6 Supercharged / 3.0L I6 Mild Hybrid, AWD)
• 2018-2022 Land Rover Range Rover (Base, SE, HSE, Autobiography, SVAutobiography, 3.0L V6 Supercharged / 4.4L V8 / 5.0L V8 Supercharged, AWD)
• 2018-2022 Land Rover Range Rover Sport (S, SE, HSE, HSE Dynamic, SVR, 2.0L I4 Turbo / 3.0L V6 Supercharged / 5.0L V8 Supercharged, AWD)

Fitment Notes

• Fitment applies to vehicles equipped with the 20-inch Brembo front brake package (380 mm rotor). Vehicles with smaller 18-inch or 19-inch brake packages use a different rotor - confirm your brake package size before ordering.
• Does not fit 2020 Land Rover Defender 110 First Edition (initial production run used a different brake specification).
• Sold individually (1 rotor per box); purchase two for a complete front axle replacement.
• All listed vehicles are AWD only.

Features

• Brembo's patented Pillar Venting Technology (PVT) channels airflow through the rotor for up to 40% greater resistance to thermal cracking versus conventional vane designs.
• Full UV coating across the entire disc surface - hub, braking surface, outer diameter, and internal vanes - provides immediate corrosion protection, ready to install out of the box.
• High-carbon cast iron construction reduces noise, vibration, and harshness (NVH) while delivering enhanced thermal stability under heavy or repeated braking.
• Meets or exceeds OEM specifications - engineered and validated to the same standards used by Land Rover on factory brake systems.
• Part number and minimum thickness stamped directly on the rotor hub for quick identification and service monitoring.
• All required fixing hardware included - direct bolt-on installation with no additional parts needed.

Specifications

• Position: Front
• Rotor Type: Vented (Pillar Venting Technology - PVT)
• Surface: Plain (non-drilled, non-slotted)
• Rotor Diameter: 380 mm (14.96 in)
• Nominal Thickness: 34 mm
• Height: 62 mm
• Centering Diameter: 79 mm
• Number of Bolt Holes: 5
• Material: High-Carbon Cast Iron
• Coating: Solvent-Free UV Coating (full disc coverage)
• Sold: Individually (1 rotor per package)
• OEM Cross-Reference: LR098968

Included Components

• 1x Brembo Prime UV-Coated PVT Vented Front Brake Rotor (09.C820.11)
• 1x Fixing Screw Kit (all mounting hardware included)

Product Description

The Brembo 09.C820.11 is a large-diameter 380 mm front brake rotor from Brembo's Prime line, engineered specifically for Land Rover's heavier SUV and off-road platforms including the Defender, Discovery, Range Rover, and Range Rover Sport. It features Brembo's patented Pillar Venting Technology (PVT), which uses a unique pillar-shaped internal vane design to maximize airflow and dramatically improve the rotor's resistance to heat-induced cracking - critical on heavier vehicles that place greater thermal demands on the braking system. The solvent-free UV coating protects the entire disc surface from the moment it arrives, eliminating prep time and guarding against corrosion throughout its service life.

Built to OEM-equivalent standards and validated to Land Rover's original specifications, this rotor installs directly in place of the factory unit with no modifications required. It pairs ideally with Brembo's NAO/Ceramic or Low-Met brake pad formulations for a complete, matched braking system. Whether servicing a daily-driven Range Rover or a more demanding Defender, the 09.C820.11 delivers Brembo's trusted stopping performance in a direct, hassle-free fitment.
