Brembo 09.D064.11 UV Coated 350mm Front Brake Rotor for 2017-2026 Jaguar XE

Vehicle Fitment

• 2017-2026 Jaguar XE (X760), RWD/AWD, equipped with 350mm front brake package

Fitment Notes

• Does not fit XE models with the standard 325mm front rotor (T4N1801)
• Verify brake package size by VIN before ordering, as multiple front rotor diameters were offered

Features

• UV-cured paint coating on hub and outer edge for corrosion resistance
• Patented Pillar Vented Technology (PVT) for improved heat dissipation
• Increases resistance to thermal cracking by over 40%
• Precision-balanced casting to reduce vibration and pedal pulsation
• OE-equivalent design, meets or exceeds original material specs
• ECE-R90 type-approved for road use
• High-carbon cast iron for durability and heat tolerance
• Direct bolt-on fit, no modification required

Specifications

• Position: Front
• Disc Type: Vented
• Diameter: 350mm
• New Thickness: 32mm
• Minimum Thickness: 30mm
• Bolt Holes: 5
• Centering Bore: 64mm
• Height: 48mm

Included Components

• 1x Brembo Front Brake Rotor

Product Description

The Brembo 09.D064.11 is a UV-coated, vented 350mm front brake rotor built as a direct OE-equivalent replacement for Jaguar XE models equipped with the larger front brake package. The Pillar Vented Technology design promotes airflow through the rotor to control heat and reduce the chance of thermal cracking under repeated braking.

The UV-cured coating protects the hub and outer edge from corrosion, helping the rotor resist rust while keeping a clean appearance over time. Tight manufacturing tolerances and balancing help reduce vibration and pulsation once installed, supporting smoother, more consistent braking.

This rotor is sold individually and suits XE owners replacing worn 350mm front discs who want a reliable, no-modification replacement matching Jaguar's original equipment specifications.
