Brembo 08.B348.41 UV Coated Rear Rotor for Mercedes CLA250 GLA250 Infiniti QX30

Vehicle Fitment

• 2014-2019 Mercedes-Benz CLA250 (C117, Base/4MATIC, 2.0L I4 Turbo, FWD/AWD)
• 2015-2020 Mercedes-Benz GLA250 (X156, Base/4MATIC, 2.0L I4 Turbo, FWD/AWD)
• 2013-2019 Mercedes-Benz B250 (W246, Base/4MATIC, 2.0L I4, Disc Brake Config Only)
• 2014-2015 Mercedes-Benz B Electric Drive (W242, Base, FWD)
• 2016-2017 Mercedes-Benz B250e (W242, Base, FWD)
• 2017-2019 Infiniti QX30 (Base, Luxury, Premium, Sport, 2.0L I4 Turbo, FWD/AWD)

Fitment Notes

• Rear axle fitment only - sold as a set of 2 rotors per box
• Mercedes-Benz B250 (W246): fitment applies to disc brake rear configurations only - some variants use rear drum brakes; confirm before ordering
• The Infiniti QX30 shares the Mercedes-Benz MFA platform with the GLA250 and uses the same rear brake specification
• Does not fit the 2020+ Mercedes-Benz GLA (W247) or 2020+ CLA (C118) - those are new-generation platforms with different brake specifications
• Mercedes-Benz OE cross-reference: A2464230112

Features

• UV paint treatment on all non-friction surfaces delivers superior corrosion resistance right out of the box
• Water-based, solvent-free UV coating process - environmentally responsible with low energy consumption
• High-carbon cast iron construction minimizes brake noise and vibration for refined daily driving
• Solid disc design engineered as a direct OE-equivalent replacement - no modifications required
• ECE-R90 certified - meets European safety standards for replacement brake discs
• Electronically balanced to tight tolerances for smooth, vibration-free braking performance
• Intelligent minimum thickness marking for quick visual wear inspection at service intervals
• Includes fixing screw kit with all hardware required for installation

Specifications

• Position: Rear (Left and Right)
• Disc Type: Solid (Non-Vented)
• Outside Diameter: 295 mm (11.61 in)
• Nominal Thickness: 10 mm
• Minimum Thickness: 8.3 mm (0.33 in)
• Overall Height: 44 mm (1.73 in)
• Center Bore: 67 mm
• Bolt Circle Diameter: 112 mm
• Lug Hole Count: 5
• Tightening Torque: 130 Nm
• Surface Finish: UV Coated / Smooth Plain
• Material: High-Carbon Gray Cast Iron
• ABS Tone Ring: Not Included
• Mercedes-Benz OE Cross-Reference: A2464230112
• Brembo Line: Prime (OE Replacement)

Included Components

• 2x Brembo UV Coated Solid Rear Brake Rotors
• 1x Fixing Screw Kit (all mounting hardware included)

Product Description

The Brembo 08.B348.41 is a UV-coated solid rear brake rotor from the Brembo Prime line, designed for the 2014-2019 Mercedes-Benz CLA250, 2015-2020 GLA250, 2013-2019 B250 (disc brake variants), 2014-2017 B Electric Drive/B250e, and 2017-2019 Infiniti QX30 - all of which share the Mercedes-Benz MFA platform and the same 295mm rear brake specification. It cross-references Mercedes-Benz OE part number A2464230112 and installs as a direct bolt-on with no modifications required.

Brembo's Prime line UV paint treatment shields the outer edges and hub from corrosion, keeping the rotor looking clean and extending service life compared to uncoated replacements. High-carbon cast iron alloy improves heat dissipation and reduces the noise and vibration typical of standard-grade iron. ECE-R90 certified for road use, this rotor ships as a set of two - one for each side of the rear axle. Note: B250 (W246) fitment applies only to disc rear brake configurations - verify your vehicle's rear brake type before ordering. This part does not fit the 2020+ GLA (W247) or 2020+ CLA (C118) new-generation platforms.
