Brembo OE 09.B805.11 Front Vented Brake Rotor 390mm for 12-19 Mercedes ML/GL

Vehicle Fitment

• 2012-2015 Mercedes-Benz ML350 (W166, AWD/4MATIC, 3.5L V6) with 390mm Front Brakes
• 2012-2015 Mercedes-Benz ML550 (W166, AWD/4MATIC, 4.7L Twin-Turbo V8)
• 2016-2019 Mercedes-Benz GLE350 (W166, RWD/AWD, 3.5L V6) with 390mm Front Brakes
• 2016-2019 Mercedes-Benz GLE400 (W166, AWD/4MATIC, 3.0L Twin-Turbo V6)
• 2016-2019 Mercedes-Benz GLE550e (W166, AWD/4MATIC, 3.0L Hybrid)
• 2013-2016 Mercedes-Benz GL450 (X166, AWD/4MATIC, 3.0L Twin-Turbo V6)
• 2013-2016 Mercedes-Benz GL550 (X166, AWD/4MATIC, 4.7L Twin-Turbo V8)
• 2017-2019 Mercedes-Benz GLS450 (X166, AWD/4MATIC, 3.0L Twin-Turbo V6)
• 2017-2019 Mercedes-Benz GLS550 (X166, AWD/4MATIC, 4.7L Twin-Turbo V8)

Fitment Notes

• Front axle brake rotor.
• For vehicles equipped with 390mm front ventilated brake discs.
• Not for AMG models equipped with larger performance brake systems.
• Verify brake package and rotor dimensions before ordering.
• Sold individually; two rotors required per vehicle.

Features

• OE-equivalent Brembo Prime Series brake rotor.
• High-carbon cast iron construction for improved thermal stability.
• PVT (Pillar Venting Technology) internal ventilation design.
• UV-coated finish for superior corrosion protection.
• Precision-machined friction surfaces.
• Factory-balanced to minimize vibration and brake pulsation.
• ECE R90 type-approved design.
• Direct-fit OE replacement installation.
• Enhanced resistance to thermal cracking.
• Engineered to meet or exceed OE braking performance.

Specifications

• Part Number: 09.B805.11
• Brand: Brembo OE
• Series: Prime
• Position: Front
• Rotor Type: Vented
• Ventilation Technology: PVT (Pillar Venting Technology)
• Diameter: 390 mm
• Nominal Thickness: 36 mm
• Minimum Thickness: 34 mm
• Height: 55 mm
• Center Bore: 67 mm
• Bolt Pattern: 5-Lug
• Material: High-Carbon Cast Iron
• Finish: UV Anti-Corrosion Coating

Included Components

• 1x Brembo OE 09.B805.11 Front Brake Rotor
• 1x Rotor Fastening Screw

Product Description

The Brembo OE 09.B805.11 Prime Front Brake Rotor is a premium OE-equivalent replacement designed for select Mercedes-Benz W166 and X166 platform SUVs equipped with 390mm front braking systems. Manufactured from high-carbon cast iron, this rotor provides exceptional heat management, braking consistency, and long-term durability for demanding luxury SUV applications.

A key feature of the 09.B805.11 rotor is Brembo's advanced Pillar Venting Technology (PVT), which improves airflow through the rotor and enhances resistance to thermal stress compared to conventional vane designs. Combined with Brembo's UV anti-corrosion coating, the rotor delivers long-lasting protection against rust while maintaining a clean OE appearance.

Precision-machined and factory-balanced to strict tolerances, this rotor offers smooth braking performance, reduced vibration, and direct OE fitment without modification. It is an ideal choice for drivers seeking factory-level braking performance and reliability from one of the world's leading braking system manufacturers.
