Brembo 09.C549.11 UV Coated PVT Front Brake Rotor for Porsche Cayenne/VW Touareg

Vehicle Fitment

• 2011-2018 Porsche Cayenne (958 / 958.2), Base / S / S Diesel / S E-Hybrid / S E-Hybrid Platinum, 3.0L V6 Diesel / 3.0L V6 Hybrid / 3.6L V6 / 4.2L V8 Diesel / 4.8L V8, AWD - equipped with 360mm front discs and silver brake calipers (Porsche option codes I1LL / I1LU)
• 2011-2017 Volkswagen Touareg (7P), V6 TDI / V6 3.6L FSI / Hybrid / R-Line / Lux, 3.0L TDI / 3.6L V6, AWD - equipped with 360mm front discs (VW PR codes 1LD / 1ZT / 1ZB)

Fitment Notes

• Fits front axle only - sold as one (1) rotor per unit; purchase two for a complete front axle replacement.
• Compatible with Porsche OE part numbers 95835140301 and 95835140401; VW OE part numbers 7P6615301, 7P6615301A, 7P6615301B.
• Fitment is specific to Cayenne 958 and Touareg 7P models equipped with 360mm front disc brakes. Verify your brake package by checking your vehicle's option/PR codes or measuring your existing rotor diameter before ordering.
• Does NOT fit Cayenne Turbo or Turbo S variants (which use larger 380mm+ front rotors and red calipers). Does not fit Cayenne 955/957 (previous generation).
• Confirm your wheel size is 18 inches or larger, as this rotor corresponds to the 18" brake package on the Cayenne 958.

Features

• Brembo's patented Pillar Venting Technology (PVT) increases airflow through the rotor, improving resistance to thermal cracking by over 40% versus conventional vane designs - critical for the performance demands of the Cayenne and Touareg.
• Full UV coating across all rotor surfaces - including internal ventilation channels - provides superior corrosion resistance from the moment it leaves the box.
• High-carbon cast iron alloy construction minimizes noise and vibration for smooth, refined braking suited to luxury SUV driving.
• Precision-machined to Brembo's strict shape tolerance values, minimizing lateral runout and delivering consistent, fade-resistant pedal response.
• Direct OE-equivalent replacement - meets or exceeds Porsche and VW factory specifications with no modifications required.
• ECE-R90 certified, meeting strict European safety and quality standards for replacement brake discs.
• Part number and minimum thickness stamped directly on the rotor for quick service identification.
• All required fixing hardware included for straightforward professional installation.

Specifications

• Position: Front Axle
• Outer Diameter: 360 mm (14.17 in)
• Nominal Thickness: 36 mm
• Minimum Thickness: 34 mm
• Height: 69 mm
• Centering Diameter: 130 mm
• Number of Bolt Holes: 5
• Disc Type: Internally Vented, Smooth Finish
• Venting Design: Brembo PVT (Pillar Venting Technology)
• Surface: UV Coated (PRIME Line)
• Material: High-Carbon Cast Iron
• OE Part Numbers: 95835140301, 95835140401 (Porsche); 7P6615301, 7P6615301A, 7P6615301B (VW)

Included Components

• 1x Brembo UV Coated PVT Front Brake Disc (09.C549.11)
• 1x Fixing Screw Kit (all required installation hardware)

Product Description

The Brembo 09.C549.11 is a UV-coated, Pillar-Vented 360mm front brake rotor engineered as a direct OE replacement for the Porsche Cayenne (958) 2011-2018 and Volkswagen Touareg (7P) 2011-2017 fitted with the standard 360mm front brake package. As a primary OEM brake supplier to both Porsche and Volkswagen Group, Brembo manufactures this rotor to the same engineering standards as the factory part, ensuring an exact-fit replacement for the Porsche OE numbers 95835140301/95835140401 and VW 7P6615301 series.

Full UV coating across the entire disc prevents pre-installation corrosion and extends service life - important in the harsh underbody environment of a luxury SUV. Brembo's Pillar Venting Technology improves heat dissipation over conventional vaned designs, delivering consistent braking confidence under both highway driving and demanding stop-and-go conditions. Always confirm your Cayenne's or Touareg's brake package (360mm front disc / silver caliper option) before ordering, as Turbo and higher-spec variants use different, larger-diameter front rotors.
