Brembo 09.C892.11 Front Rotor for 2006-2014 VW Golf/GTI 1.8T/2.0L

Vehicle Fitment

• 2006-2008 Volkswagen Golf (Mk5/1K, 1.6L I4, 1.9L TDI I4, 2.0L I4, FWD)
• 2006 Volkswagen Golf GTI (Mk5/1K, 1.8L Turbo I4, FWD)
• 2006-2009 Volkswagen Rabbit (Mk5/1K, 2.5L I5, FWD)
• 2008 Volkswagen Golf R32 (Mk5/1K, 3.2L VR6, 4Motion AWD)
• 2008-2014 Volkswagen GTI (Mk5/Mk6, 2.0L Turbo I4, FWD)
• 2010-2013 Volkswagen Golf (Mk6/5K, 1.6L/2.0L I4, FWD)
• 2012-2013 Volkswagen Golf R (Mk6/5K, 2.0L Turbo I4, 4Motion AWD)
• 2006-2010 Volkswagen Passat (B6/3C, 3.6L VR6/FSI V6, 4Motion AWD where equipped)
• 2009-2012 Volkswagen CC (B6/3C, 2.0L Turbo I4/3.6L VR6, FWD/4Motion AWD where equipped)
• 2009-2010 Volkswagen Passat CC (B6/3C, 2.0L Turbo I4/3.6L VR6, FWD/4Motion AWD where equipped)
• 2006-2009 Volkswagen Eos (1F, 2.0L Turbo I4/3.2L VR6, FWD)
• 2003-2013 Audi A3 (8P/8P1/8PA, applicable 1.2L-3.2L I4/V6 configurations, FWD/quattro)
• 2005-2013 SEAT Leon (1P, applicable 1.6L-2.0L I4 configurations, FWD)
• 2008-2015 Skoda Superb II (3T, applicable 1.8L-3.6L I4/V6 configurations, FWD/4x4)
• 2008-2017 Volkswagen Scirocco (Mk3/137/138, 2.0L R/TSI configurations, FWD/4Motion where equipped)

Fitment Notes

• Front axle application; rotor is designed for the specified 345 mm brake configuration.
• Applicable vehicles may use FWD, 4Motion AWD, quattro, or 4x4 depending on model, engine, and market configuration.
• Vehicle-specific brake packages must be verified because not every engine or trim within a listed platform uses the 345 mm rotor.
• Golf R and R32 applications require the factory high-performance brake configuration corresponding to this rotor size.
• Some European-market Audi, SEAT, Skoda, and Volkswagen applications extend beyond the North American model-year ranges shown in common U.S. catalogs.
• Not a universal rotor; confirm the factory rotor diameter, thickness, hub dimensions, and brake package before installation.

Features

• Brembo Prime Line OE-equivalent front brake rotor.
• 345 mm outside diameter provides the specified braking surface.
• 30 mm nominal thickness matches the applicable factory brake configuration.
• 27 mm minimum thickness defines the specified wear limit.
• Internally ventilated PVT construction promotes efficient heat dissipation.
• High-carbon cast-iron construction provides enhanced thermal and mechanical resistance.
• UV-painted protective coating helps resist corrosion on exposed rotor surfaces.
• 65 mm centering diameter provides the specified hub interface.
• Five-hole mounting configuration matches compatible VAG applications.
• OE-equivalent design is intended as a direct replacement without vehicle modification.
• Supplied with the required fixing screw for the applicable installation.
• ECE-R90 type-approved Brembo Prime design.

Specifications

• Brand: Brembo
• Part Number: 09.C892.11
• Product Line: Prime
• Product Type: Brake Disc Rotor
• Position: Front
• Outside Diameter: 345 mm
• Nominal Thickness: 30 mm
• Minimum Thickness: 27 mm
• Overall Height: 50 mm
• Centering Diameter: 65 mm
• Mounting Holes: 5
• Brake Disc Type: Internally Ventilated / PVT
• Material: High-Carbon Cast Iron
• Surface Treatment: UV Coated
• OE-Equivalent: Yes
• ECE-R90 Type Approved: Yes
• EAN: 8020584228968
• Replaces Brembo Part Number: 09.A201.10
• Compatible OE References: 1K0615301M, 1K0615301AB, 1K0615301AR

Included Components

• 1x Brembo 09.C892.11 Front Brake Rotor
• 1x Fixing Screw

Product Description

The Brembo 09.C892.11 Prime Front Brake Rotor is an OE-equivalent replacement designed for compatible Volkswagen, Audi, SEAT, and Skoda vehicles using the 345 mm front brake configuration. Measuring 345 mm in diameter and 30 mm in nominal thickness, the internally ventilated rotor is engineered around the factory dimensions required by compatible VAG performance and passenger-car applications.

Brembo uses high-carbon cast iron for enhanced thermal and mechanical resistance, while its PVT ventilation design supports heat management during repeated braking. The rotor features a 65 mm center bore, five mounting holes, a 50 mm overall height, and a 27 mm minimum thickness. A UV protective coating helps resist corrosion, and the Prime rotor is ECE-R90 type approved.

The 09.C892.11 covers a broad range of VAG applications, including selected Volkswagen Golf, GTI, Golf R, R32, Rabbit, Passat, CC, Passat CC, Eos, and Scirocco models, plus compatible Audi A3, SEAT Leon, and Skoda Superb configurations. Because several of these platforms were offered with multiple brake sizes, engines, and drivetrains, the factory 345 mm rotor specification should be confirmed before installation. The rotor is supplied individually with a fixing screw.
