Brembo 09.A426.11 UV Coated Front Rotor for Volvo S60 S80 V60 V70 XC70 Ford

Vehicle Fitment

• 2007-2016 Volvo V70 III (all trims and engines - 1.6D, 2.0, 2.0D, 2.5T, 3.2, 3.2 AWD, D3/D4, D5, D5 AWD, T4, T4F, T5, T6 AWD)
• 2007-2016 Volvo XC70 II (all trims and engines - 2.4D, 3.2 AWD, D3, D4, D4 AWD, D5 AWD, T5, T6 AWD)
• 2006-2016 Volvo S80 II (all trims and engines - 1.6D, 2.0, 2.0D, 2.4D, 2.5T, 3.2, 3.2 AWD, D2, D3/D4, D4, D5, D5 AWD, T4, T4F, T5, T6 AWD, V8 AWD)
• 2010-2018 Volvo S60 II (all trims and engines - 1.5T, 1.6D, 2.0T, 2.5T, D2, D3, D4, D4 AWD, D5, D5 AWD, T2, T3, T4, T4F, T5, T5 AWD, T6, T6 AWD; including Cross Country and Polestar variants)
• 2010-2018 Volvo V60 I (all trims and engines - 1.5T, 1.6D, 2.0T, D2, D3, D4, D4 AWD, D5, D5 AWD, D5 Hybrid AWD, D6 Hybrid AWD, T2, T3, T4, T4F, T5, T5 AWD, T6 AWD; including Cross Country and Polestar variants)
• 2006-2014 Ford S-MAX (WA6) - 2.0 EcoBoost (146-176 kW), 2.2 TDCi (129 kW), 2.5 ST (162 kW)
• 2008-2015 Ford Galaxy II (WA6) - 2.0 EcoBoost (146-149 kW), 2.2 TDCi (129 kW)
• 2006-2014 Land Rover Freelander 2 (L359) - 2.0 Si4 4x4 (177 kW), 3.2 4x4 (171 kW)

Fitment Notes

• Front axle fitment only - sold individually (1 rotor per box); two units required for a complete front axle replacement
• Volvo S60 II Cross Country and V60 I Cross Country variants included across all production dates listed
• Applies across all engine types on the listed Volvo platforms - petrol, diesel, hybrid, BioPower/FlexFuel, and Polestar variants all share this 316mm front rotor specification
• Fits both manual and automatic transmissions unless otherwise noted by your VIN
• Primary OE cross-references: Volvo 30769061 / 307690610 / 314007640; Ford 1380046 / 1404955 / 1405509 / 1434812 / 1434815 / 1864276; Land Rover LR000470 / LR027107
• Wheel tightening torque: 170 Nm

Features

• UV paint treatment on all non-friction surfaces - including internal venting chambers - provides full corrosion protection immediately out of the box, with no pre-cleaning required before installation
• Water-based, solvent-free UV paint process - environmentally responsible and low-energy compared to conventional coating methods
• High-carbon cast iron alloy delivers enhanced thermal stability, superior heat dissipation, and reduced noise and vibration versus standard-grade iron
• Pillar Venting Technology (PVT) - Brembo's patented internal pillar venting geometry increases airflow for up to 40% greater resistance to thermal cracking compared to conventional straight-vane designs
• Direct OE-equivalent replacement - bolt-on fit with no modifications required for all listed vehicles
• ECE-R90 certified - meets European safety standards for replacement brake discs
• Electronically balanced to tight manufacturing tolerances to minimize runout and pedal pulsation
• Includes fixing screw kit with all mounting hardware required for installation

Specifications

• Position: Front (Left or Right)
• Disc Type: Vented
• Outside Diameter: 316 mm (12.44 in)
• Nominal Thickness: 28 mm
• Minimum Thickness: 26 mm
• Overall Height: 52 mm
• Center Bore: 64 mm
• Lug Hole Count: 5
• Tightening Torque: 170 Nm
• Surface Finish: UV Coated / Smooth Plain
• Material: High-Carbon Cast Iron
• ABS Tone Ring: Not Included
• OE Cross-References: Volvo 30769061; Ford 1380046; Land Rover LR000470
• Brembo Line: Prime (OE Replacement)

Included Components

• 1x Brembo UV Coated Vented Front Brake Rotor
• 1x Fixing Screw Kit (all mounting hardware included)

Product Description

The Brembo 09.A426.11 is a 316mm UV-coated vented front brake rotor from the Brembo Prime line, covering a broad range of Ford, Land Rover, and Volvo platforms produced from approximately 2006 through 2018. On the Volvo side it fits every variant of the S60 II, V60 I, S80 II, V70 III, and XC70 II - encompassing all petrol, diesel, hybrid, FlexFuel, and Polestar configurations on those platforms, including Cross Country derivatives. Ford applications include the S-MAX and Galaxy II (WA6 generation) in higher-output EcoBoost and TDCi trims, while Land Rover coverage includes the Freelander 2 in both 2.0 Si4 and 3.2-litre variants. Primary OE cross-reference numbers are Volvo 30769061, Ford 1380046, and Land Rover LR000470.

This rotor is sold individually - one per box - so two are needed for a full front axle service. Brembo's UV paint treatment coats every non-friction surface including the internal venting passages, providing ready-to-install corrosion protection using an eco-friendly, solvent-free water-based process. Combined with high-carbon cast iron construction and Brembo's patented PVT pillar venting geometry, the 09.A426.11 meets or exceeds OE thermal and comfort performance for these platforms, and is ECE-R90 certified as a direct replacement.
