Brembo 09.9768.11 UV-Coated Rear Rotor for Audi TT/TTS/TT RS Quattro

Vehicle Fitment

• 2008-2009 Audi TT Quattro
• 2012-2013 Audi TT RS Quattro
• 2009-2015 Audi TTS Quattro

Features

• UV-coated surface for enhanced corrosion protection
• High-carbon cast iron construction for durability and reduced noise
• Pillar-vented design for improved heat dissipation and thermal resistance
• OE-equivalent design for direct replacement of factory rotor
• Markings indicate part number and minimum usable thickness
• Includes fixing screw kit for easy installation
• ECE R-90 certified for safety and performance
• Compatible with Brembo NAO, Ceramic, or Low-Met brake pads

Specifications

• Outer Diameter: 310 mm
• Nominal Thickness: 22 mm
• Minimum Thickness: 20 mm
• Height: 58.2 mm
• Centering Diameter: 65 mm
• Number of Bolt Holes: 5
• Tightening Torque: 120 Nm
• Brake Disc Type: Internally vented (pillar-vented)

Included Components

• 1x UV-coated rear brake rotor (09.9768.11)
• 1x Fixing screw kit

Product Description

The Brembo 09.9768.11 rear rotor delivers OE-equivalent braking performance for select Audi Quattro models. Its UV-coated finish protects against corrosion, while the high-carbon cast iron construction minimizes noise and vibration.

The pillar-vented design ensures optimal heat dissipation and thermal resistance. Installation is straightforward with the included fixing screws, and intelligent markings help track rotor wear. Pair with Brembo NAO, Ceramic, or Low-Met pads for maximum braking performance and longevity.
