Brembo 09.D716.11 UV Coated Front Rotor for 2007-2017 Lexus LS460/LS460L 4.6L

Vehicle Fitment

• 2007-2017 Lexus LS460 (Base, without Sport Package), 4.6L V8, RWD
• 2007-2017 Lexus LS460L (Long Wheelbase, without Sport Package), 4.6L V8, RWD

Fitment Notes

• Fits the 334mm front rotor configuration - applies to RWD LS460 and LS460L models without the Sport Package
• Does NOT fit LS460 models equipped with the Sport Package - Sport Package models use a larger Brembo front rotor (approximately 357mm) and different caliper
• Does NOT fit LS460 AWD models - AWD configuration uses a different front rotor specification
• Does NOT fit Lexus LS600h or LS600hL - hybrid models use a separate brake specification
• Sold as a single rotor (1x per box); two required per front axle
• Verify your front rotor diameter (334mm) and confirm no Sport Package before ordering

Features

• OE-equivalent design - direct replacement for Lexus/Toyota OE part 4351250240 with no modifications required
• Brembo Pillar Vented Technology (PVT) channels air through internal pillars for over 40% greater crack resistance versus conventional vane designs
• Full-surface UV coating protects the braking band, hat, and internal ventilation chambers from corrosion without pre-installation cleaning required
• High-carbon cast iron construction minimizes vibration and brake noise for the refined, quiet character expected in a flagship luxury sedan
• Electronically balanced at the factory to minimize runout and vibration straight out of the box
• ECE R-90 certified for international safety and performance compliance
• Part number and minimum thickness engraved directly on the disc for easy service inspection
• Solvent-free UV coating process - up to 98% less energy and CO2 versus traditional zinc or paint treatments

Specifications

• Position: Front Axle
• Disc Type: Vented
• Surface: UV Coated
• Diameter: 334mm (13.15 in.)
• OE Reference: 4351250240 (Lexus / Toyota)
• Units per Box: 1

Included Components

• 1x Brembo Prime UV Coated Front Brake Rotor (09.D716.11)
• 1x Fixing screw kit with all hardware required for installation

Product Description

The Brembo 09.D716.11 is a Prime Line OE-equivalent front brake rotor engineered for the Lexus LS460 and LS460L (2007-2017) in RWD configuration without the Sport Package. Replacing Lexus OE part 4351250240, this rotor is built with high-carbon cast iron and finished in Brembo's solvent-free UV coating - delivering superior corrosion resistance across the full disc surface from day one, no cleaning required before installation. The internally vented design incorporates Brembo's patented Pillar Vented Technology (PVT), channeling airflow through the rotor for enhanced heat dissipation and significantly improved resistance to thermal cracking under sustained braking loads.

Fitment is rotor-size specific. The LS460 RWD uses three distinct front rotor sizes depending on trim: this 334mm rotor is correct for base models without the Sport Package. Confirm your brake configuration before ordering. Brembo recommends replacing both front rotors as a pair and pairing with Brembo NAO/Ceramic or Low Met brake pad formulations for optimal performance and pad compatibility. Complete a proper bedding procedure after installation.
