Brembo 09.B648.11 UV Front Brake Rotor 296mm for 07-16 Honda CR-V/07-09 RDX

Vehicle Fitment

• 2007-2009 Acura RDX (Base, AWD) -- Front
• 2007-2016 Honda CR-V (All Trims, FWD / AWD) -- Front

Fitment Notes

• Front axle only -- sold individually (order 2 for a complete front axle set)
• 2012-2016 Honda CR-V: AWD trims only per fitment table
• OEM rotor reference: 45251SWE000 (CR-V) / 45251STKA00 (RDX)
• Companion front pad: Brembo P28068N (replaces P28054N)
• Complete front kit (rotors + pads): Brembo KT00084
• Companion rear rotor: Brembo 08.A355.11

Features

• PRIME UV Coated -- solvent-free coating protects full disc including braking surfaces
• Corrosion resistant -- installs right out of the box
• High-carbon grey cast iron -- minimizes noise and vibration
• Intelligent minimum thickness marking -- visible on disc surface
• Fixing screw kit included -- simple and safe installation
• Meets or exceeds OEM specifications

Specifications

• Part Number: 09.B648.11
• Series: PRIME UV Coated
• Position: Front
• Type: Vented
• Outside Diameter: 296mm (11.65")
• Nominal Thickness: 28mm
• Discard Thickness: 26mm
• Overall Height: 47mm
• Center Hole Diameter: 64.20mm
• Lug Holes: 5
• Surface: Smooth / Plain
• Material: Gray Cast Iron
• Coating: UV (solvent-free)
• OEM Reference: 45251SWE000 / 45251STKA00
• Weight: 8.32 lbs.
• UPC: 8020584215166
• Quantity: 1 rotor per pack

Included Components

• 1x Brembo PRIME UV Coated Front Brake Rotor (09.B648.11)
• Fixing screw kit

Product Description

The Brembo 09.B648.11 is a PRIME UV Coated front brake rotor for the 2007-2009 Acura RDX and 2007-2016 Honda CR-V. At 296mm diameter and 28mm nominal thickness, this vented rotor is a direct OEM-equivalent replacement for the front axle of these Honda and Acura platforms. As an original equipment supplier to Honda and Acura, Brembo engineers this replacement to the same dimensional and metallurgical standards as the factory-installed rotor.

The PRIME UV Coated finish is a solvent-free UV coating applied to the full disc surface -- including the braking faces -- providing corrosion resistance from the moment it leaves the box without requiring break-in or cleaning before installation. The gray cast iron construction minimizes noise, vibration, and harshness under normal and aggressive braking. Minimum thickness is laser-marked directly on the disc for quick visual inspection during service. Fixing screws are included. Sold individually -- order two for a complete front axle set. Companion front pad is Brembo P28068N; complete front rotor and pad kit is KT00084. Rear companion rotor is 08.A355.11.
