Brembo 09.A407.11 Coated Vented Front Rotor for 02-06 RSX Type-S/05-11 Civic Si

Vehicle Fitment

• 2002-2006 Acura RSX Type-S (2.0-L I4; FWD; 5-hole 114.3-mm bolt pattern)
• 2006-2011 Honda Civic Si (2.0-L I4; FWD; 5-hole 114.3-mm bolt pattern)
• 2005-2006 Honda CR-V (2.4-L I4; FWD/AWD; 5-hole 114.3-mm)

Fitment Notes

• UV-coated vented front rotor, full cast gray iron, 300-mm diameter; OEM bolt pattern and height
• Direct OEM replacement matching factory specifications including thickness, height, and mounting PCD
• Sold individually - order quantity of 2 for both front wheels
• Not compatible with Civic non-Si, RSX base or other Accord/CR-V years and trims

Features

• Premium UV corrosion-resistant coating - eco-friendly, solvent-free finish
• Full cast gray iron with high carbon content for vibration and noise reduction
• Ventilated design promotes superior heat dissipation
• Precision-balanced, meets or exceeds OE fit and finish
• Supplied with mounting screw for hassle-free installation
• ECE-R90 certified as OEM-equivalent part
• Torque spec: 108-Nm for proper installation
• Ideal to pair with Brembo NAO pads for optimal braking performance

Specifications

• Part Type: Front Ventilated Disc Brake Rotor
• Rotor Count: 1 (single)
• Diameter: 300-mm
• Nominal Thickness: 25-mm; Minimum Thickness: 23-mm
• Height: 47-mm
• Bolt Pattern: 5 - 114.3-mm; Center bore: 64.2-mm
• Material: High-carbon gray cast iron
• Fitment: Acura RSX Type-S (02-06), Honda Civic Si (06-11), Honda CR-V (05-06); front axle only
• Weight: approx.-17.4-lb
• Warranty: 2-Year Limited

Included Components

• 1- UV-coated vented front brake rotor
• 1- mounting screw
• Installation instructions

Product Description

The Brembo 09.A407.11 UV-Coated Ventilated Front Rotor is a direct OEM fit replacement for 2002-2006 Acura RSX Type-S, 2006-2011 Honda Civic Si, and 2005-2006 Honda CR-V front axle applications. Featuring a corrosion-resistant UV coating, this 300-mm rotor offers improved appearance and long-term durability while matching or exceeding OEM braking performance.

Manufactured from high-carbon cast iron with ventilated design, it ensures heat dissipation under repeated braking and reduces vibration or noise. The precise 5-bolt, 114.3-mm pattern and 64.2-mm bore height align exactly with OEM mounting points. Torque installation to spec (108-Nm) using the included screw.

ECE-R90 certified for quality and sold individually, this rotor is ideal to pair with Brembo's premium brake pads for enhanced comfort and safety. Backed by a 2-Year Limited Warranty, it provides a long-lasting, reliable upgrade for select Honda and Acura sport models.
