BorgWarner 179428 EFR Wastegate Actuator Bracket Kit 62-76mm CW 0.83 0.94 TH

Vehicle Fitment

• Universal - compatible with BorgWarner EFR 7163 (62mm CW) with 0.83 A/R and 0.94 A/R turbine housing
• Universal - compatible with BorgWarner EFR 7670 (76mm CW) with 0.83 A/R and 0.94 A/R turbine housing
• Universal - compatible with BorgWarner EFR 8370 (76mm CW) with 0.83 A/R and 0.94 A/R turbine housing

Fitment Notes

• Designed for BorgWarner EFR B1 and B2 frame turbochargers with 62mm-76mm compressor wheels and 0.83 or 0.94 A/R turbine housings - does NOT fit EFR turbos with 83mm or 91mm compressor wheels (use 179429 for those)
• For EFR 62mm and 67mm CW turbos with 0.64 A/R turbine housing, use BorgWarner bracket kit 179427 instead
• For EFR 83mm and 91mm CW turbos (EFR 8374, 9180, etc.), use BorgWarner bracket kit 179429 instead
• Required when purchasing an EFR Super Core with an internal wastegate (IWG) turbine housing - IWG housings do not include actuator brackets
• Compatible with standard and super short wastegate canisters (low, medium, and high boost variants)
• Universal performance/custom fitment - vehicle-specific installation may require additional fabrication

Features

• Genuine OEM BorgWarner actuator bracket kit - same hardware supplied with EFR turbo assemblies
• Stainless steel construction for sustained heat resistance and durability in high-temperature turbo environments
• Mounts to the bearing housing backing plate - allows turbo clocking changes without repositioning the wastegate bracket
• Compatible with standard and super short EFR wastegate canisters for flexible boost setup
• Supports low, medium, and high boost canister configurations as defined in BorgWarner's official Wastegate Selection Guide
• Includes all fasteners and hose hardware needed for a complete installation - no extra parts required
• Direct-fit for compatible EFR 7163, 7670, and 8370 turbos - no drilling or modification required
• Supplied new in genuine BorgWarner packaging

Specifications

• Part Number: 179428
• Kit Type: Wastegate Canister Actuator Bracket Kit
• Brand: BorgWarner
• Compressor Wheel Size Compatibility: 62mm-76mm CW
• Turbine Housing A/R Compatibility: 0.83 A/R and 0.94 A/R
• Compatible EFR Models: EFR 7163, EFR 7670, EFR 8370
• Bracket Material: Stainless Steel
• Signal Hose Length: 410mm (long)
• Application: Universal performance/custom

Included Components

• 1x Stainless Steel Wastegate Actuator Bracket
• 3x Bracket-to-Bearing Housing Screws
• 2x Canister-to-Bracket Lock Nuts
• 1x Actuator Rod Nut (outboard side)
• 1x Wastegate Signal Hose (410mm long)
• 2x Hose Clamps

Product Description

The BorgWarner 179428 is the genuine OEM wastegate canister actuator bracket kit for EFR turbochargers equipped with 62mm-76mm compressor wheels and 0.83 or 0.94 A/R turbine housings - specifically the EFR 7163, EFR 7670, and EFR 8370. This bracket kit is required when a wastegate canister is being installed on an EFR Super Core or any separately purchased IWG turbine housing, as these do not include actuator mounting hardware.

Unlike most turbocharger designs, the EFR bracket mounts directly to the bearing housing backing plate rather than the compressor housing, which allows the turbo clocking position to be changed without repositioning the wastegate bracket. The complete stainless steel hardware kit supports standard and super short canister types across all three boost spring configurations (low, medium, high) as specified in BorgWarner's official Wastegate Selection Guide. For EFR turbos with 83mm or 91mm compressor wheels, use bracket kit 179429 instead.
