BMR RSK017H Rear Suspension Kit for 1968-1972 GM A-Body

Vehicle Fitment

• 1968-1972 Buick Skylark (Base, Custom, 350)
• 1968-1972 Chevrolet Chevelle (Base, Malibu, SS, Concours, Nomad, 300, 300 Deluxe)
• 1968-1972 Oldsmobile Cutlass (Base, 442, Supreme)
• 1968-1972 Pontiac GTO
• 1968-1972 Pontiac LeMans

Features

• Non-adjustable design for consistent performance
• 95-durometer internally fluted polyurethane greasable bushings
• Zinc-coated inner sleeves for corrosion resistance
• DOM steel tubing construction for strength and durability
• 1.625-inch diameter, 0.120-inch wall tubing upper control arms
• 1.50-inch diameter, 0.120-inch wall tubing lower control arms
• 1.0-inch diameter, 0.156-inch wall tubing control arm reinforcement braces
• MIG-welded upper and lower control arms; TIG-welded reinforcement braces
• Reduces control arm flex and bushing deflection
• Improves performance with acceptable NVH levels
• Control arm reinforcement braces reduce frame deflection
• Designed for street performance, drag race, and road race applications
• Durable powdercoat finish
• 3-4 hour installation time
• Proudly designed and made in the U.S.A.

Specifications

• Material: DOM steel tubing
• Finish: Black Hammertone powdercoat
• Bushing Type: 95-durometer internally fluted polyurethane greasable
• Upper Control Arm Dimensions: 1.625-inch diameter, 0.120-inch wall
• Lower Control Arm Dimensions: 1.50-inch diameter, 0.120-inch wall
• Reinforcement Brace Dimensions: 1.0-inch diameter, 0.156-inch wall
• Installation Time: Approximately 3-4 hours

Included Components

• 2x Upper Control Arms
• 2x Lower Control Arms
• 2x Control Arm Reinforcement Braces
• All necessary hardware for installation

Product Description

The BMR RSK017H Rear Suspension Kit is designed to enhance the performance of 1968-1972 GM A-body vehicles, including the Buick Skylark, Chevrolet Chevelle, Oldsmobile Cutlass, and Pontiac GTO. This non-adjustable kit features heavy-duty DOM steel tubing construction, providing increased strength and durability for street performance, drag racing, and road racing applications.

Equipped with 95-durometer internally fluted polyurethane greasable bushings and zinc-coated inner sleeves, the RSK017H kit offers improved handling and reduced wheel hop. The inclusion of control arm reinforcement braces helps to reduce frame deflection, ensuring better stability during aggressive driving. With a durable black Hammertone powdercoat finish, this kit not only performs well but also adds a sleek look to your vehicle's undercarriage.

Installation is straightforward, with an estimated time of 3-4 hours. All necessary hardware is included, making it a comprehensive solution for upgrading your vehicle's rear suspension system.
