BLOX Racing BXSS-20354-20-BK Front Bump Steer Kit 20mm Black 00-09 Honda S2000

Vehicle Fitment

• 2000-2009 Honda S2000 (AP1 and AP2) - Front

Fitment Notes

• For lowered S2000s only - this kit is not needed or beneficial on a stock-height vehicle. Designed for S2000s lowered more than approximately 1.5". For vehicles lowered approximately 1" to 1.5", the 12mm version (BXSS-20354-12-BK) provides the appropriate correction and is recommended instead.
• Front axle position only - one kit covers both front tie rod outer ends (2 spacers included).
• Black anodized finish (BK suffix). Also available in blue, gold, purple, red, and silver color variants under corresponding part number suffixes.
• Installs at the outer tie rod end, between the tie rod end and the steering knuckle. A wheel alignment is required after installation.

Features

• BLOX Racing 20mm front bump steer correction kit for the 2000-2009 Honda S2000 - a pair of CNC-machined billet aluminum spacers that correct the outer tie rod geometry on lowered S2000s with more aggressive drops. When the S2000 is lowered, the changed suspension geometry alters the angle of the outer tie rod relative to the steering knuckle. This causes the effective toe angle to shift dynamically through suspension travel - bump steer - which produces steering pull and wheel tug under cornering and over road imperfections. The 20mm spacers reposition the outer tie rod end upward to restore the intended tie rod angle at greater ride height reductions where the 12mm spacer would be insufficient for full correction.
• CNC-machined billet aluminum - precision machined for consistent spacer thickness and flat mating surfaces, ensuring correct geometry correction without introducing play or misalignment at the tie rod end joint.
• Black anodized finish - corrosion-resistant and visually clean within the wheel well.
• Recommended for S2000s lowered beyond approximately 1.5" - the greater 20mm offset provides the additional correction required at this drop range. Vehicles lowered approximately 1" to 1.5" should use the 12mm kit (BXSS-20354-12-BK).
• Manufactured to ISO 9001 certified standards.

Specifications

• Part Number: BXSS-20354-20-BK
• Color/Finish: Black Anodized
• Material: CNC-Machined Billet Aluminum
• Spacer Thickness: 20mm
• Position: Front Outer Tie Rod
• Recommended Lowering Range: Beyond ~1.5"
• Quantity: 2 Spacers (covers both front corners)

Included Components

• 2x BLOX Racing 20mm Billet Aluminum Bump Steer Spacers (Black Anodized)
• Installation Hardware

Product Description

The BLOX Racing BXSS-20354-20-BK is a 20mm front bump steer correction kit for the 2000-2009 Honda S2000 (AP1/AP2), consisting of two CNC-machined billet aluminum spacers in black anodized finish and the necessary installation hardware. The 20mm kit is designed for S2000s lowered beyond approximately 1.5" - drops at which the 12mm kit (BXSS-20354-12-BK) does not provide sufficient geometry correction. At greater ride height reductions, the outer tie rod angle deviation from the factory geometry is larger, and the additional 8mm of spacer offset in the 20mm kit provides the correspondingly greater correction needed to reduce or eliminate bump steer.

Bump steer on the S2000 manifests as steering pull or wheel tug felt during cornering or when the suspension moves over road imperfections - a result of the effective toe angle changing dynamically as the suspension compresses and rebounds. The 20mm spacers reposition the outer tie rod end upward at the knuckle, restoring the tie rod angle closer to factory specification at the new ride height. A wheel alignment is required after installation. Also available in blue, gold, purple, red, and silver anodized finishes. For S2000s lowered approximately 1" to 1.5", the 12mm kit (BXSS-20354-12-BK) is the appropriate choice.
