BLOX Racing BXSS-20354-12-BK Front Bump Steer Kit 12mm Black 00-09 Honda S2000

Vehicle Fitment

• 2000-2009 Honda S2000 (AP1 and AP2) - Front

Fitment Notes

• For lowered S2000s only - this kit is not needed or beneficial on a stock-height vehicle. Designed for S2000s lowered approximately 1" or more, up to approximately 1.5". For vehicles lowered beyond 1.5", the 20mm version (BXSS-20354-20-BK) is recommended instead.
• Front axle position only - one kit covers both front tie rod outer ends (2 spacers included).
• Black anodized finish (BK suffix). Also available in blue, gold, purple, red, and silver color variants under corresponding part number suffixes.
• Installs at the outer tie rod end, between the tie rod end and the steering knuckle. A wheel alignment is required after installation.

Features

• BLOX Racing 12mm front bump steer correction kit for the 2000-2009 Honda S2000 - a pair of CNC-machined billet aluminum spacers that correct the outer tie rod geometry on lowered S2000s. When the S2000 is lowered, the front suspension drop changes the angle of the outer tie rod relative to the steering knuckle. This altered geometry causes the effective toe angle to change through suspension travel - a condition known as bump steer - which manifests as unwanted steering pull or "wheel tug" during cornering and over road imperfections. The BLOX spacers reposition the outer tie rod end upward to restore the factory-intended tie rod angle at the new ride height, reducing or eliminating the bump steer effect.
• CNC-machined billet aluminum - precision machined for consistent spacer thickness and flat mating surfaces, ensuring correct geometry correction without introducing play or misalignment at the tie rod end joint.
• Black anodized finish - corrosion-resistant and visually clean within the wheel well.
• Recommended for lowered S2000s - approximately 1" to 1.5" of lowering. The 12mm spacer thickness is calibrated for this drop range. Vehicles lowered beyond 1.5" should use the 20mm kit (BXSS-20354-20-BK) for full correction.
• Manufactured to ISO 9001 certified standards.

Specifications

• Part Number: BXSS-20354-12-BK
• Color/Finish: Black Anodized
• Material: CNC-Machined Billet Aluminum
• Spacer Thickness: 12mm
• Position: Front Outer Tie Rod
• Recommended Lowering Range: ~1.0" to ~1.5"
• Quantity: 2 Spacers (covers both front corners)

Included Components

• 2x BLOX Racing 12mm Billet Aluminum Bump Steer Spacers (Black Anodized)
• Installation Hardware

Product Description

The BLOX Racing BXSS-20354-12-BK is a 12mm front bump steer correction kit for the 2000-2009 Honda S2000 (AP1/AP2), consisting of two CNC-machined billet aluminum spacers in black anodized finish and the necessary installation hardware. The kit addresses a well-known issue on lowered S2000s: when the vehicle is dropped from stock ride height, the outer tie rod end angle relative to the steering knuckle changes, causing the effective toe setting to shift through suspension travel - commonly felt as steering pull or wheel tug during cornering or over bumps. The 12mm spacers reposition the outer tie rod end upward at the knuckle, restoring the tie rod angle toward the factory geometry at the new ride height.

The 12mm kit is suited for S2000s lowered approximately 1" to 1.5". For vehicles lowered beyond 1.5", the 20mm variant (BXSS-20354-20-BK) provides the additional correction needed. A wheel alignment is required after installation. Also available in blue, gold, purple, red, and silver anodized finishes.
