Bilstein 22-249241 B6 Front Strut/Shock for 14-24 Dodge Ram ProMaster 1500/2500

Vehicle Fitment

• 2014-2023 Ram ProMaster 1500 - FWD
• 2014-2024 Ram ProMaster 2500 - FWD
• 2014-2023 Ram ProMaster 3500 - FWD

Fitment Notes

• Front axle position only
• Suspension strut assembly -- strut body only, uses OEM coil spring
• Fits all engine options (3.0L EcoDiesel, 3.6L Pentastar V6)
• Fits all body styles (cargo van, cab & chassis, cutaway)
• Supersedes previous Bilstein part number 22-292216
• Companion rear shock: Bilstein 24-245500
• OE cross-references: 68157782AC, 68157782AF, 68157783AC, 68157783AF, 68241284AB, 68241284AC, 68268192AB, 68274700AB

Features

• B6 Series front suspension strut assembly
• Twin-tube gas pressure design for consistent damping
• Velocity-sensitive digressive piston adjusts to road conditions
• Application-specific valving tuned for Ram ProMaster platform
• Fixed spring seat included -- uses factory coil spring
• Durable steel body with yellow corrosion-resistant coating
• Direct bolt-on replacement for factory front strut
• Improved ride quality, handling, and load control over OE

Specifications

• Part number: Bilstein 22-249241
• Previous part number: 22-292216
• Series: B6
• Type: Suspension strut assembly
• Position: Front
• Internal design: Twin-tube
• Upper mount: Stem
• Lower mount: Base cup
• Compressed length: 19.53"
• Extended length: 26.81"
• Spring seat: Yes (fixed)
• Boot included: No
• Reservoir: No
• Finish: Yellow paint
• Weight: 17.7 lbs
• UPC: 651860783987
• EAN: 4025258780197
• Warranty: Limited lifetime (original purchaser)
• Sold individually

Included Components

• (1) Bilstein B6 front suspension strut assembly
• Fixed spring seat (pre-installed)

Product Description

The Bilstein 22-249241 is a B6 Series front suspension strut assembly designed as a direct bolt-on upgrade for 2014-2024 Ram ProMaster 1500, 2500, and 3500 vans. The ProMaster's front-wheel-drive layout places significant demand on the front struts, which must manage steering loads, braking forces, and payload weight simultaneously. The 22-249241 addresses this with a twin-tube gas pressure design and Bilstein's velocity-sensitive digressive piston, which automatically adjusts damping force based on input speed -- providing firm control over large impacts while remaining compliant over smaller road imperfections. Each unit is individually tuned specifically for the ProMaster platform to optimize ride quality, stability, and load-carrying capability at stock ride height. The strut assembly includes a fixed spring seat and accepts the factory coil spring and upper mount, simplifying installation with no additional hardware required. A durable steel body with Bilstein's signature yellow corrosion-resistant coating ensures long service life in commercial-use environments. This part supersedes the earlier 22-292216 and pairs with the Bilstein 24-245500 rear shock absorber for a complete B6 suspension upgrade. Backed by Bilstein's limited lifetime warranty for the original purchaser.
