Bilstein 24-309516 B8 5100 Rear Shock for 2019-2025 Chevy/GMC 1500 4WD

Vehicle Fitment

• 2019-2025 Chevrolet Silverado 1500 (All Trims, 4WD, Rear; stock or slight lift)
• 2019-2025 GMC Sierra 1500 (All Trims, 4WD, Rear; stock or slight lift)
• 2022 Chevrolet Silverado 1500 LTD/Limited (All Trims, 4WD, Rear)
• 2022 GMC Sierra 1500 Limited (All Trims, 4WD, Rear)

Features

• Bilstein B8 5100 Series rear shock absorber with monotube gas-pressurized design
• Engineered for 1500 pickups with stock ride height and slight rear lift tolerances
• Velocity-sensitive digressive piston for responsive damping and control
• Enhanced handling, stability, and ride quality over OEM rear shocks
• Durable zinc-plated corrosion-resistant finish
• Black protective straight boot included
• Direct bolt-on replacement - no modifications required
• Limited lifetime manufacturer warranty

Specifications

• Part Number: 24-309516
• Series: Bilstein B8 5100
• Position: Rear (Driver or Passenger Side)
• Internal Design: Monotube gas-pressurized
• Damping: Non-adjustable
• Body Diameter: ~46 mm
• Upper Mount Type: Eyelet (~14.1 mm)
• Lower Mount Type: Eyelet (~14.1 mm)
• Compressed Length: ~17.40"
• Extended Length: ~27.61"
• Boot Included: Yes (Black Straight)
• Recommended Lift: Compatible with slight rear lift (approx. 0-1" on Trail Boss/AT4)

Included Components

• 1x Bilstein B8 5100 Rear Shock Absorber (24-309516)
• 1x Black protective boot installed

Product Description

The Bilstein 24-309516 B8 5100 Rear Shock Absorber is a high-performance monotube gas-pressurized shock engineered for the rear suspension of Chevrolet Silverado 1500 and GMC Sierra 1500 pickup trucks from the 2019 through 2025 model years, including the 2022 LTD/Limited variants. Tuned for stock ride height and slight rear lift applications, this shock features a velocity-sensitive digressive piston that reacts quickly to changing road and load conditions, providing improved handling, stability, and ride quality over standard factory rear shocks.

Installation is straightforward - the 24-309516 shock bolts directly into the original rear mounting points on 4WD models with no modifications required, reusing factory hardware. The corrosion-resistant zinc-plated finish and protective straight boot help extend service life in varied driving conditions. Sold individually, it's recommended to replace both rear shocks at the same time for balanced suspension performance and smoother ride quality on your Silverado or Sierra.
