Bilstein 24-336345 B8 5100 Front Shock for 2023-2026 Chevy Colorado 4WD

Vehicle Fitment

• 2023-2026 Chevrolet Colorado WT (2WD & 4WD)
• 2023-2026 Chevrolet Colorado LT (2WD & 4WD)
• 2023-2026 Chevrolet Colorado Z71 (4WD)

Fitment Notes

• Front position only - sold individually; order two for a complete front pair
• Designed for 3rd-generation Chevrolet Colorado (2023+) - does NOT fit 2015-2022 (2nd-gen) Colorado, which uses Bilstein part number 24-292702
• Lift range: 0 to 3 inches of front lift using factory OE springs - actual maximum lift varies by trim and suspension configuration; refer to Bilstein's installation instructions for snap-ring position and corresponding lift heights for your specific Colorado
• Uses factory OE coil springs - no spring replacement required; the adjustable spring seat collar repositions along the shock body to set the desired lift height
• Eliminates the need for aftermarket coil spacers or separate leveling kit hardware - the B8 5100 provides lift and performance improvement in a single unit
• All necessary installation hardware included; factory mounting bolts are reused
• For 2023+ Colorado Trail Boss: confirm fitment with Bilstein before ordering - the Trail Boss may use a different front suspension specification requiring a separate part number

Features

• Bilstein B8 5100 (Ride Height Adjustable) product line - Bilstein's premier front coilover-style shock for trucks and SUVs combining lift capability and performance in a single unit
• Multiple snap-ring grooves on the shock body allow manual adjustment of the spring seat collar to set lift height - 0 inches (stock), leveled, or up to 3 inches of lift depending on setting
• 46mm monotube gas pressure design with digressive piston - large-diameter single-tube construction delivers consistent fade-free performance, superior heat dissipation, and increased wheel travel vs. stock
• Self-adjusting deflective disc valve setting - Bilstein's patented digressive valving instantly reacts to changing road and off-road conditions for maximum comfort and control on any surface
• Accommodates larger aftermarket tires - increased ground clearance at higher lift settings allows fitment of larger tires without rubbing
• Improved off-road capability - increased wheel travel and performance valving provide superior obstacle absorption and terrain handling compared to factory shocks
• Eliminates clunky coil spacers - the B8 5100 lifts the vehicle using Bilstein's integrated spring seat design while maintaining OEM spring technology and suspension geometry
• Black boot included for shock rod protection

Specifications

• Product Line: Bilstein B8 5100 (Ride Height Adjustable)
• Position: Front (sold individually - order 2 for complete front pair)
• Shock Type: 46mm Monotube Gas Pressure
• Piston: Self-adjusting digressive deflective disc valve
• Front Lift Range: 0-3 inches (using factory OE springs; varies by setting)
• Adjustment Method: Multiple snap-ring grooves on shock body for spring seat repositioning
• Boot Included: Yes (black)
• Springs Required: Factory OE springs (no replacement springs needed)
• Vehicle: 2023-2026 Chevrolet Colorado (WT, LT, Z71)
• Warranty: Limited Lifetime (original purchaser; against defects in workmanship and materials)

Included Components

• 1x Bilstein B8 5100 Ride Height Adjustable Front Shock Absorber (46mm monotube)
• Black dust boot
• All necessary installation hardware
• Note: Factory coil springs are reused; factory mounting bolts are reused

Product Description

The Bilstein 24-336345 is a B8 5100 Ride Height Adjustable front shock absorber designed specifically for the 2023-2026 Chevrolet Colorado (3rd generation) in WT, LT, and Z71 trims. It is the definitive front suspension upgrade for Colorado owners who want to level the truck, add 0-3 inches of front lift, improve off-road capability, and fit larger tires - all without separate coil spacers, leveling kits, or spring replacement.

The B8 5100's adjustable spring seat collar slides along multiple snap-ring grooves on the shock body, allowing precise manual adjustment of the front ride height using the factory coil springs. The 46mm monotube construction with Bilstein's patented self-adjusting digressive disc valve delivers consistent, fade-free damping across all terrain types - improving on the factory shock's performance while accommodating the increased wheel travel that comes with the lift. Order two for a complete front pair. Note: this part is specific to the 2023+ 3rd-gen Colorado - the 2015-2022 2nd-gen Colorado uses Bilstein part 24-292702.
