Bilstein 53-333377 B12 Rear Coil Spring Set 1in Lift 2024-2026 Toyota Tacoma 4WD

Vehicle Fitment

• 2024-2026 Toyota Tacoma SR5 (4WD) - i-Force Engine Only
• 2024-2026 Toyota Tacoma TRD Sport (4WD) - i-Force Engine Only
• 2024-2026 Toyota Tacoma TRD Off-Road (4WD) - i-Force Engine Only
• 2024-2026 Toyota Tacoma Limited (4WD) - i-Force Engine Only

Fitment Notes

• Engine restriction - i-Force only: This spring set fits the 2.4L turbocharged i-Force engine ONLY - does NOT fit the i-Force Max (2.4L turbo hybrid) engine, which uses different rear suspension specifications
• 4WD applications only - fitment for 2WD Tacoma rear suspension not confirmed for this part number
• Rear position only - this is a rear coil spring set; front lift requires a separate front component (struts or spacers)
• Does NOT fit 2024+ Tacoma TRD Pro or Trailhunter - these trims use unique factory suspension tuning that may conflict with aftermarket spring rates
• Springs only - no shock absorbers included; existing factory rear shocks or aftermarket shocks must be used with these springs
• Sold as a set (pair) - includes both driver and passenger rear coil springs

Features

• Bilstein B12 (Special) product line - engineered to optimize ride height performance while maintaining the suspension dynamics and ride quality expected from a Bilstein product
• 1 inch rear lift raises the Tacoma's rear ride height for improved ground clearance, a leveled stance front-to-rear, and accommodation of larger aftermarket tires
• Progressive spring rate design provides a comfortable ride under normal driving conditions while increasing resistance proportionally under heavier loads or off-road impacts
• High-strength steel coil construction - engineered to Bilstein's OEM-grade specifications for consistent spring rate and long-term shape retention
• Direct-fit replacement for factory rear coil springs - installs in the existing spring perches without modification
• Designed specifically for the 4th-generation Tacoma's rear suspension geometry and i-Force engine weight distribution

Specifications

• Product Line: Bilstein B12 (Special)
• Product Type: Rear Coil Spring Set (pair)
• Position: Rear
• Rear Lift: 1 inch
• Engine: i-Force (2.4L turbo) only - NOT for i-Force Max hybrid
• Drivetrain: 4WD
• Shocks Included: No - springs only
• Quantity: Set of 2 (driver + passenger)
• Vehicle: 2024-2026 Toyota Tacoma 4WD (i-Force engine, select trims)
• Warranty: Lifetime Limited (Bilstein gas pressure warranty; applies to original purchaser)

Included Components

• 2x Bilstein B12 (Special) Rear Coil Springs (driver and passenger side)
• Note: Shock absorbers are NOT included - compatible with factory rear shocks or Bilstein B8 5100/5160 rear shocks for the 4th-gen Tacoma

Product Description

The Bilstein 53-333377 is a B12 (Special) rear coil spring set delivering a 1 inch rear lift for the 2024-2026 Toyota Tacoma 4WD equipped with the i-Force (2.4L turbocharged) engine. It is engineered specifically for the 4th-generation Tacoma's rear suspension geometry and is not compatible with the i-Force Max hybrid variant, which uses different rear spring specifications due to the added weight of the hybrid battery system.

The 1 inch rear lift brings the Tacoma's rear ride height up to better match a leveled front stance, improves ground clearance, and accommodates slightly larger aftermarket tire sizes without rubbing. The B12 (Special) progressive spring rate delivers a comfortable daily-driving ride character while providing increased support under load or off-road conditions. Sold as a pair (driver and passenger rear springs) - shock absorbers are not included and must be sourced separately. Compatible with factory rear shocks or Bilstein's own B8 5100 or 5160 rear shocks for the 4th-generation Tacoma platform.
