Bilstein 47-336674 B8 6112 Front Lift Kit 0-2.5in for 2023-2026 Chevy Colorado

Vehicle Fitment

• 2023-2026 Chevrolet Colorado WT (2WD/RWD, 2.7L TurboMax I4)
• 2023-2026 Chevrolet Colorado WT (4WD, 2.7L TurboMax I4)
• 2023-2026 Chevrolet Colorado LT (2WD/RWD, 2.7L TurboMax I4)
• 2023-2026 Chevrolet Colorado LT (4WD, 2.7L TurboMax I4)
• 2023-2026 Chevrolet Colorado Z71 (4WD, 2.7L TurboMax I4)

Fitment Notes

• Does NOT fit the Chevrolet Colorado Trail Boss - Trail Boss models have a factory-installed 2-inch front lift with a longer strut assembly; a separate Bilstein application-specific kit is required for Trail Boss.
• Does NOT fit the Chevrolet Colorado ZR2 or ZR2 Bison - these trims use proprietary Multimatic DSSV dampers and a 3-inch factory lift that are not compatible with this kit.
• Front position only - this kit covers the front suspension only. Two units are included (left and right). Rear shocks are sold separately.
• Lift height is adjustable within the 0-2.5 inch range using multiple snap-ring grooves on the strut body; final lift depends on spring perch position selected during installation.
• Wheel alignment is required after installation and after any subsequent ride height adjustment.
• Compatible with both 2WD (RWD) and 4WD drivetrain configurations on applicable WT and LT trims.

Features

• Adjustable front lift from 0 to 2.5 inches using multiple snap-ring grooves in the coilover body - allows precise leveling or lifting without the need for spacers or separate lift components.
• Large 60mm (2.65" OD) digressive piston provides significantly increased damping control over conventional 46mm shock absorbers, improving both on-road handling and off-road composure.
• Oversized 60mm shock body increases oil volume capacity for superior heat management during sustained off-road use, trail running, and loaded driving conditions.
• Two custom cold-wound matched coil springs are included - engineered specifically for the 2023-2026 Colorado front suspension geometry to maintain proper spring rate and compression travel at the selected lift height.
• Two billet aluminum spring seats are included - providing a precise, durable mounting point for the included springs and ensuring long-term dimensional stability.
• Velocity-sensitive digressive valve settings are tuned specifically for the 4th-generation Chevrolet Colorado platform, optimizing compression and rebound for both daily driving and off-road demands.
• Increases front wheel travel compared to factory struts, improving off-road articulation and reducing the bottoming-out tendency under hard terrain impacts.
• Allows fitment of larger aftermarket tires by providing additional front clearance with the lifted ride height.
• Direct bolt-on fit using OE factory front strut mounting points - no cutting, drilling, or welding required.
• Backed by Bilstein's lifetime limited warranty for the original purchaser against defects in materials and workmanship.

Specifications

• Part Number: 47-336674
• Series: B8 6112 - Coilover Front Suspension Kit
• Position: Front (complete front kit - left and right included)
• Piston Diameter: 60mm digressive
• Shock Body OD: 2.65 inches (60mm)
• Front Lift Range: 0-2.5 inches (adjustable via snap-ring grooves)
• Spring Type: Custom matched cold-wound coil springs (2x included)
• Spring Seat: Billet aluminum (2x included)
• Gas Charge: High-pressure nitrogen monotube
• Drivetrain Compatibility: 2WD (RWD) and 4WD
• Package Weight: 51.3 lbs
• Package Dimensions: 30.63" L x 13.38" W x 5.0" H
• Warranty: Lifetime limited (Bilstein dampers, original purchaser)

Included Components

• 2x Bilstein B8 6112 Front Coilover Struts (left and right)
• 2x Custom Matched Cold-Wound Coil Springs
• 2x Billet Aluminum Spring Seats

Product Description

The Bilstein 47-336674 B8 6112 is a complete front coilover suspension kit engineered specifically for the 2023-2026 Chevrolet Colorado in WT, LT, and Z71 trim levels - excluding the Trail Boss and ZR2, which use factory-lifted suspension systems not compatible with this kit. The B8 6112 represents a significant upgrade from basic leveling spacers or standard 5100 RHA struts, combining Bilstein's oversized 60mm coilover shock body with matched cold-wound coil springs and billet aluminum spring seats in a single, purpose-built package. The result is a front suspension system that levels or lifts the Colorado between 0 and 2.5 inches while simultaneously delivering a meaningful improvement in damping performance, wheel travel, and off-road capability.

The 60mm shock body - significantly larger than the 46mm diameter found on conventional dampers - houses a 60mm digressive piston with velocity-sensitive valve settings tuned to the Colorado's platform. The larger bore provides higher oil volume for improved heat management during sustained off-road use, and the digressive piston design delivers a damping curve that is compliant at low suspension speeds (small bumps, highway undulations) and progressively firmer at high speeds (hard hits, washboard roads, cornering loads). Multiple snap-ring grooves in the strut body allow the spring perch position to be adjusted during installation, enabling the installer to dial in the exact front lift height desired - from stock height all the way to 2.5 inches - to achieve a level stance or accommodate larger aftermarket tires.

This kit applies to all 2023-2026 Colorado models across both 2WD and 4WD configurations in the covered trims, and every Colorado in this generation uses the same 2.7L TurboMax turbocharged I4 engine, meaning engine-based fitment variations do not apply. The kit is front-only - rear shock upgrades are available separately. OE mounting hardware is reused during installation, and no chassis modifications are required. Wheel alignment must be performed after installation to maintain proper suspension geometry. Backed by Bilstein's lifetime limited warranty on the dampers, the 47-336674 is the definitive bolt-on front suspension upgrade for Colorado WT, LT, and Z71 owners who want more capability without compromise.
