Bilstein 25-311976 B8 5160 Rear Shock for 2007-2018 Jeep Wrangler JK 4WD

Vehicle Fitment

• 2007-2018 Jeep Wrangler JK (4WD, all trims)

Features

• Designed for rear lifts of 1.5-3 inches
• Remote reservoir enhances oil capacity and cooling
• Monotube design for consistent fade-free performance
• Velocity-sensitive, digressive valving tuned for each application
• 360° swivel banjo hose fitting for clean, low-profile installation
• Billet reservoir clamp included
• Corrosion-resistant zinc-plated finish with clear coating
• Direct fit installation using factory mounting points

Specifications

• Collapsed Length: 14.95 inches (379.7 mm)
• Extended Length: 25.03 inches (635.7 mm)
• Body Diameter: 46mm
• Upper Mount Type: Bar Pin
• Lower Mount Type: Eye (12.1mm)
• Reservoir: Yes
• Boot Included: No
• Spring Seat Included: No
• Adjustable Damping: Non-adjustable

Included Components

• 1x Bilstein 25-311976 Rear B8 5160 Shock Absorber
• 1x Billet Reservoir Clamp
• All necessary washers, bushings, and nuts for installation
• Factory shock mounting bolts are reused for installation

Product Description

The Bilstein 25-311976 B8 5160 rear shock absorber is engineered to enhance the off-road performance of your 2007-2018 Jeep Wrangler JK 4WD. Designed for vehicles with 1.5 to 3 inches of rear lift, this shock absorber features a remote reservoir that increases oil capacity and cooling, ensuring consistent fade-free performance during demanding off-road conditions.

Constructed with a 46mm monotube design, the B8 5160 utilizes velocity-sensitive, digressive valving tuned for each specific application. This design adapts to varying road conditions, offering a smooth and controlled ride both on and off the road. The shock absorber is finished with a corrosion-resistant zinc-plated coating with a clear coating, providing excellent durability in harsh environments.

Installation is straightforward, utilizing factory mounting points and including all necessary hardware. Please note that the Bilstein 25-311976 shock absorber does not include a boot or spring seat. For vehicles with 1.5-3 inches of rear lift, this shock absorber is an ideal choice to maintain ride quality and handling performance.
