BBK 1710 80mm Power Plus Throttle Body for 1996-1998 Chevy GMC Vortec 305/350 V8

Vehicle Fitment

• 1996-1998 Chevrolet C1500 (5.0L V8 305, 5.7L V8 350 Vortec)
• 1996-1998 Chevrolet C1500 Suburban (5.0L V8 305, 5.7L V8 350 Vortec)
• 1996-1997 Chevrolet C2500 (5.0L V8 305, 5.7L V8 350 Vortec)
• 1996-1997 Chevrolet C2500 Suburban (5.0L V8 305, 5.7L V8 350 Vortec)
• 1996-1998 Chevrolet K1500 (5.0L V8 305, 5.7L V8 350 Vortec)
• 1996-1998 Chevrolet K1500 Suburban (5.0L V8 305, 5.7L V8 350 Vortec)
• 1996-1998 Chevrolet K2500 (5.0L V8 305, 5.7L V8 350 Vortec)
• 1996-1998 Chevrolet K2500 Suburban (5.0L V8 305, 5.7L V8 350 Vortec)
• 1996-1998 Chevrolet Tahoe (5.7L V8 350 Vortec)
• 1996-1998 Chevrolet Express 1500 (5.0L V8 305, 5.7L V8 350 Vortec)
• 1996-1997 Chevrolet Express 2500 (5.0L V8 305, 5.7L V8 350 Vortec)
• 1999 Chevrolet C2500 (5.7L V8 350 Vortec)
• 1996-1998 GMC C1500 (5.0L V8 305, 5.7L V8 350 Vortec)
• 1996-1998 GMC C1500 Suburban (5.0L V8 305, 5.7L V8 350 Vortec)
• 1996-1997 GMC C2500 (5.0L V8 305, 5.7L V8 350 Vortec)
• 1996-1997 GMC C2500 Suburban (5.0L V8 305, 5.7L V8 350 Vortec)
• 1996-1998 GMC K1500 (5.0L V8 305, 5.7L V8 350 Vortec)
• 1996-1998 GMC K1500 Suburban (5.0L V8 305, 5.7L V8 350 Vortec)
• 1996-1998 GMC K2500 (5.0L V8 305, 5.7L V8 350 Vortec)
• 1996-1998 GMC K2500 Suburban (5.0L V8 305, 5.7L V8 350 Vortec)
• 1996-1997 GMC Yukon (5.7L V8 350 Vortec)
• 1996-1998 GMC Savana 1500 (5.0L V8 305, 5.7L V8 350 Vortec)
• 1996-1998 GMC Savana 2500 (5.0L V8 305, 5.7L V8 350 Vortec)
• 1997-1998 GMC Savana 3500 (5.7L V8 350 Vortec)

Fitment Notes

• Does NOT fit 1998 GM 2500 models - see BBK Part #1709 for that application.
• Does NOT fit any 1996-1998 GM 454 (7.4L V8) applications - see BBK Part #1709.
• Cable-style throttle actuation only - not compatible with drive-by-wire applications.
• CARB Approved for legal use in all 50 states - CARB E.O. Number D-245-17.
• No tune required - works with the factory ECU and stock calibration.

Features

• Large 80mm throttle body bore delivers up to 30% more airflow over the factory unit for gains of 7-12 RWHP.
• CNC machined from high-quality 356 aluminum castings for precise OEM-quality fit and long-term durability.
• OEM-style die-stamped throttle linkages maintain factory drivability and smooth cable-actuated pedal feel.
• Double-sealed bearings and O-ringed throttle shafts eliminate air leaks and extend service life.
• Direct bolt-on replacement - no modifications required for a hassle-free installation.
• Includes spacer plate required for proper fitment on GM Vortec applications.
• Designed to work with the factory tune - no ECU recalibration required.
• Designed and manufactured in the USA by BBK Performance.

Specifications

• Throttle Body Style: Single Bore
• Bore Size: 80mm
• Throttle Actuation: Cable Style
• Material: 356 Cast Aluminum
• Finish: Natural (Uncoated Aluminum)
• TPS Sensor Included: No
• IAC Motor Included: No
• Estimated Power Gain: 7-12 RWHP
• CARB Status: Approved - E.O. D-245-17 (Legal in all 50 states)
• Warranty: 1-Year Limited Factory Warranty

Included Components

• 1x 80mm Power Plus Series Throttle Body Assembly
• 1x Spacer Plate
• 1x Set of Required Gaskets
• 1x Installation Hardware Kit

Product Description

The BBK 1710 80mm Power Plus Series Throttle Body is a direct bolt-on performance upgrade engineered for 1996-1998 GM trucks and SUVs equipped with the Vortec 305 or 350 V8 engine. By replacing the restrictive factory throttle body with a significantly larger 80mm bore, this BBK unit delivers up to 30% more airflow to the engine, resulting in 7-12 rear-wheel horsepower gains along with noticeably sharper throttle response and improved acceleration across the RPM range - all without requiring any tune or ECU modifications.

Machined from high-quality 356 aluminum on state-of-the-art CNC equipment, the BBK 1710 delivers an exact OEM-quality fit and installs without modification using the included spacer plate, gaskets, and hardware. OEM-style die-stamped throttle linkages, double-sealed bearings, and O-ringed throttle shafts ensure long-term reliability while preserving factory cable-actuated drivability. CARB approved (E.O. D-245-17) and legal in all 50 states, this throttle body is the ideal bolt-on upgrade for any GMT400 platform truck or SUV owner looking to extract more power from their Vortec V8.
