Baja Designs 5500012 Squadron Sport Black LED Spot Light Pod Clear Universal

Vehicle Fitment

• Universal - Fits Trucks, Jeeps, SUVs, UTVs, ATVs, and Off-Road Vehicles

Fitment Notes

• Universal mount design; vehicle-specific brackets may be required for certain applications
• Wiring harness (part# 640117) sold separately - not included with this light
• Spot pattern designed for use alongside Wide Cornering or Driving/Combo lights for complete trail coverage
• Not E-approved; verify local regulations before on-road use

Features

• Spot beam pattern (9°) delivers a long, focused beam for trail and distance illumination in Lighting Zones 4 & 5
• Outputs 3,150 lumens using 4 Cree LEDs at 26W - strong output at an entry-level price point
• Matte black powder coated housing provides a subtle, understated appearance compared to the gloss Squadron Pro
• ClearView® optics deliver precise, usable light output with minimal scatter
• MoistureBlock™ system provides waterproof, rain-proof, and submersible protection (IP69K)
• CopperDrive® technology drives LEDs at 100% rated power for consistent output
• uService® design allows field replacement of lenses and optics without full unit swap
• Exceeds MIL-STD-810G military-spec vibration and impact standards

Specifications

• Lumens: 3,150 (4 Cree LEDs)
• Wattage / Amps: 26W / 2.0A
• Color Temperature: 5,000K Daylight
• Beam Pattern: Spot (9°)
• Lighting Zones: 4 & 5
• Lens Color: Clear
• Housing Color: Black (Matte Powder Coat)
• Dimensions: 3.07" W x 2.77" H x 3.07" D
• Weight: 12 oz
• LED Life Expectancy: 49,930 hours
• Front Lens: Hard Coated Polycarbonate (Clear)
• Housing: Powder Coated Cast Aluminum (Black)
• Bezel: Billet Machined Aluminum
• Hardware & Bracket: Stainless Steel
• Waterproof Rating: IP69K (Submersible to 9 ft)
• Impact Rating: IK10 Compliant
• Built-In Overvoltage Protection: Yes

Included Components

• 1x Squadron Sport LED Light Pod (Black Housing, Clear Lens, Spot Pattern)
• 1x Stainless Steel Mounting Bracket
• Note: Wiring harness not included (sold separately, part# 640117)

Product Description

The Baja Designs Squadron Sport 5500012 is the entry-level sibling to the Squadron Pro, sharing the same compact 3" form factor and proven Baja Designs construction at a more accessible price point. It delivers 3,150 lumens through a focused 9° Spot beam using 4 Cree LEDs at just 26 watts - ideal for near-field, side, backup, and scene lighting applications where maximum throw distance is needed. The matte black powder coated housing gives it a clean, low-key look that integrates well on a wide range of vehicles.

Despite the lower price point, the Squadron Sport carries the same core Baja Designs build quality - IP69K waterproof rated, IK10 impact compliant, MIL-STD-810G certified, and backed by a Limited Lifetime Warranty. uService® serviceability allows lens and optic swaps in the field. The Spot pattern works best when paired with a Wide Cornering or Driving/Combo light for complete coverage. This is a single-pod listing - wiring harness sold separately.
