Baja Designs 703003 S8 30" Driving/Combo LED Light Bar 13,560 Lumens

Vehicle Fitment

• Universal -- fits any vehicle with appropriate mounting location

Fitment Notes

• Universal fit -- requires vehicle-specific brackets or mounting solution
• Wiring harness NOT included -- use Baja Designs 640122 (sold separately)
• Straight single-row light bar design
• Stainless steel mounting hardware included
• uService replaceable lenses and optics

Features

• S8 series slim single-row 30" LED light bar
• Driving/Combo beam pattern -- 42° wide driving + 6° spot
• Maximum trail coverage with smooth near-to-far light blend
• Amber backlight feature for accent/visibility
• ClearView optics with upgraded high-performance reflectors
• CopperDrive -- LEDs driven at 100% output
• MoistureBlock -- waterproof, rain proof, submersible to 9 ft
• 5000K daylight color -- reduces driver fatigue
• Built-in overvoltage protection
• Scalloped housing design

Specifications

• Part Number: 703003
• Series: S8
• Length: 30"
• Beam Pattern: Driving/Combo (42° wide driving + 6° spot)
• Lumens: 13,560
• LEDs: 24x Cree (8 per 10" section)
• Wattage: 120W
• Amperage: 9.99A
• Color Temperature: 5000K
• Dimensions: 30" x 3" x 1.6"
• Weight: 5.1 lbs
• LED Life: 49,930 hours
• Lens: Clear hard-coated polycarbonate
• Housing: Aircraft-grade aluminum, Mil-Spec hard anodize
• Bezel: Billet machined aluminum
• Hardware: Stainless steel
• Waterproof Rating: IP69K (submersible to 9 ft, pressure washable)
• Impact Rating: IK10
• Military Standard: Exceeds MIL-STD810G
• UPC: 852156007231
• Made in USA

Included Components

• 1x Baja Designs S8 30" LED light bar
• Stainless steel mounting brackets
• Mounting hardware

Product Description

The Baja Designs 703003 is an S8 series 30-inch single-row LED light bar in the Driving/Combo beam pattern, delivering 13,560 lumens from 24 Cree LEDs across three 10-inch sections. The Driving/Combo optics combine a 42° wide driving pattern for near-field peripheral coverage with a focused 6° spot pattern for long-range distance illumination -- providing maximum trail coverage in a single light. The S8 features CopperDrive technology that drives every LED at full 100% output, ClearView optics with upgraded high-performance reflectors, and a built-in amber backlight for accent illumination and added visibility on the trail.

The slim scalloped housing is machined from aircraft-grade aluminum with Mil-Spec hard anodize and a billet aluminum bezel, protecting a clear hard-coated polycarbonate lens. Rated IP69K waterproof (submersible to 9 feet and pressure washable), IK10 impact compliant, and exceeding MIL-STD810G military specification testing. The uService design allows field-replaceable lenses and optics without replacing the entire unit. Wiring harness sold separately (Baja Designs 640122). Drawing only 9.99 amps at 120 watts with a 5000K daylight color temperature and 49,930-hour LED life expectancy. Backed by Baja Designs' 30-day satisfaction guarantee and limited lifetime warranty. Made in the USA.
