ATI 916105 Serpentine Supercharger Pulley 8-Rib 5% OD for 09-15 CTS-V/Camaro ZL1

Vehicle Fitment

• 2009-2015 Cadillac CTS-V (LSA 6.2 L supercharged V8)
• 2012-2015 Chevrolet Camaro ZL1 (LSA 6.2 L supercharged V8)

Fitment Notes

• Supercharger drive pulley only--requires ATI Super Damper compatible crank hub
• Not compatible with LT4 2016+ platforms or other engines
• Sold individually; belt not included

Features

• 8-rib serpentine design engineered for LSA supercharger drive belt
• 5 % overdrive increases boost and RPM outputs over OEM pulley
• Precision-machined aluminum shell with black anodized finish
• Steel hub for strength under high RPM loads
• Compatible only with ATI Super Damper harmonic balancers
• Manufactured to ATI's performance tolerances for engine accessories

Specifications

• Pulley Diameter: 8.295 in (≈210.6 mm) drive diameter
• Grooves: 8-rib serpentine belt interface
• Material: machined aluminum shell; steel hub assembly
• Overdrive: approx. 5 % industry-calibrated for LSA supercharger pulley
• Finish: black anodized body with raw steel hub
• Quantity: single pulley, sold individually

Included Components

• 1x ATI 916105 serpentine supercharger drive pulley (8-rib, 5 % OD)
• No hardware, belts, or damper included--pulse damper required separately

Product Description

The ATI 916105 8-rib serpentine supercharger pulley provides a 5 % overdrive to the LSA supercharger on 2009-2015 Cadillac CTS-V and 2012-2015 Camaro ZL1 models. Precision-engineered from machined aluminum with a steel hub, this OEM-style pulley integrates with the ATI Super Damper harmonic balancer to drive the blower faster, resulting in higher boost and horsepower.

With a measured drive diameter of approximately 8.295 in, it matches OEM belt size and geometry while delivering upgraded boost response. To install, you'll need a compatible ATI damper and standard belt routing. Designed for high RPM stability under performance conditions, this pulley is a trusted choice among LSA-powered performance builds.
