AST ASTLS-19-207 Lowering Springs 30mm/30mm for 18-24 Tesla Model 3 Long Range

Vehicle Fitment

• 2018-2024 Tesla Model 3 (Long Range AWD, Dual Motor)
• 2018-2024 Tesla Model 3 (Long Range Performance AWD, Dual Motor)

Fitment Notes

• Designed specifically for Long Range AWD Model 3 applications.
• Performance AWD applications are included where cataloged for this part number.
• Standard Range, Standard Range Plus, and rear-wheel-drive Model 3 applications are not confirmed for ASTLS-19-207.
• Do not substitute this part for ASTLS-19-310, ASTLS-19-311, or ASTLS-19-312, which are cataloged for RWD Model 3 applications.
• Because the Model 3 has a long wheelbase and reduced ground clearance after lowering, additional care may be required over speed bumps and steep inclines.
• Vehicles with factory lowering may achieve less additional drop than the nominal spring specification.
• 2025-2026 fitment is not independently confirmed for ASTLS-19-207 and is therefore excluded.

Features

• Vehicle-specific AST lowering spring set for Tesla Model 3 AWD applications.
• Approximately 30 mm front lowering.
• Approximately 30 mm rear lowering.
• Progressive spring design balances lowering with everyday drivability.
• Designed and tested for use with factory dampers.
• Direct replacement for the applicable OEM coil springs.
• Manufactured from high-tensile chromium-silicon spring wire.
• Cold-coiled construction for consistent spring geometry.
• Heat-treated to increase hardness and reduce stresses created during winding.
• Individually shot-peened to improve fatigue resistance.
• Phosphate-treated and powder-coated for improved corrosion protection.
• Computer-tested before shipment to help minimize settling after installation.
• Lower center of gravity helps improve body control and handling response.
• Lifetime warranty against spring breakage.

Specifications

• Brand: AST Suspension
• Part Number: ASTLS-19-207
• Product Type: Lowering Springs
• Vehicle: Tesla Model 3
• Platform: Model 3
• Compatible Trim: Long Range AWD
• Compatible Trim: Long Range Performance AWD
• Drivetrain: AWD / Dual Motor
• Front Lowering: Approximately 30 mm
• Rear Lowering: Approximately 30 mm
• Spring Design: Progressive
• Position: Front and Rear
• Damper Compatibility: Factory/OEM dampers
• Construction: High-tensile chromium-silicon wire
• Warranty: Lifetime warranty against breaking

Included Components

• 1x AST Lowering Spring Set

Product Description

The AST ASTLS-19-207 Lowering Springs are designed for 2018-2024 Tesla Model 3 Long Range AWD and Long Range Performance AWD models. The progressive spring set lowers the vehicle approximately 30 mm at both the front and rear, reducing the center of gravity and helping improve body control while maintaining compatibility with the factory dampers.

AST manufactures these springs from high-tensile chromium-silicon wire using a cold-coiling process. Each spring is heat treated, individually shot peened, phosphate treated, powder coated, and computer tested to support consistent spring characteristics and long-term durability. The progressive design is intended to provide a balance between a lower stance, improved handling response, and practical road manners.

This application is specifically cataloged for AWD Long Range and Performance Model 3 configurations. RWD and Standard Range variants use different AST spring part numbers and should not be substituted. After installation, wheel alignment and suspension-related settings should be checked, and the reduced ground clearance should be considered when driving over steep inclines or large speed bumps.
