ARB/Old Man Emu 63027 Nitrocharger Plus Rear Shock for 96-02 4Runner/Prado 90

Vehicle Fitment

• 1996-2002 Toyota 4Runner (3rd Generation, 2.7L I4 3RZ-FE, 3.4L V6 5VZ-FE)
• 1996-2002 Toyota Land Cruiser Prado 90 Series (2.7L I4 3RZ-FE, 3.0L I4 1KZ-TE Turbo Diesel, 3.0L I4 1KD-FTV Turbo Diesel, 3.4L V6 5VZ-FE)

Fitment Notes

• Designed for vehicles with 0-2 inch lift applications
• This shock replaces the earlier Old Man Emu part number 60027
• Recommended for medium to heavy load applications
• Firm valving for enhanced control with heavier loads and off-road use
• Compatible with both 4WD and RWD configurations

Features

• Twin-tube design with outer reserve tube for superior component protection
• Heavy-gauge 1.6mm steel construction--23% stronger than standard 1.3mm tubing
• Integrated high-flow piston reduces aeration and heat buildup
• Vehicle-specific valving minimizes body roll and improves steering response
• Multi-deflective disc stacking on piston for precise damping control
• Super strong 18mm induction hardened chrome piston rod
• High-performance hydraulic fluid resists fade and aeration
• Vehicle-specific polyurethane and rubber bushes for extended life
• Polyamide dirt shield protects from stone chips and debris
• Nitrogen gas-charged for consistent performance across all terrain

Specifications

• Position: Rear
• Design: Twin-Tube Gas Shock
• Extended Length: 20.9 inches
• Compressed Length: 12.9 inches
• Body Diameter: 2.28 inches (58mm)
• Piston Rod Diameter: 18mm induction hardened chrome
• Reserve Tube Wall Thickness: 1.6mm heavy-gauge steel
• Body Color: Yellow
• Bushing Material: Polyurethane and rubber composite
• Valving Type: Firm (medium to heavy load)
• Lift Compatibility: 0-2 inch (50mm) lift applications
• Warranty: 3 Years / 35,000 Miles

Included Components

• 1x Old Man Emu Nitrocharger Plus Rear Shock Absorber
• 1x Set of vehicle-specific mounting bushings and hardware
• 1x Polyamide dirt shield (pre-installed)

Product Description

The Old Man Emu 63027 Nitrocharger Plus rear shock absorber is the upgraded replacement for the earlier 60027 model, delivering enhanced off-road performance specifically engineered for 1996-2002 Toyota 4Runner and Prado 90 Series vehicles. This twin-tube gas shock combines Old Man Emu's proven Australian outback testing experience with advanced damping technology to provide vehicle-specific performance that works seamlessly with OME coil springs for both touring and daily driving applications.

Engineered with a heavy-gauge 1.6mm steel reserve tube offering 23% more protection than standard tubing, the 63027 provides exceptional durability against stone damage on loose surfaces. The integrated high-flow piston minimizes aeration and reduces oil temperature, maintaining consistent damping performance under severe conditions. With its 18mm induction hardened chrome piston rod and multi-deflective disc valving, this shock delivers precise control over compression and rebound, minimizing body roll whether climbing trails or cruising highways.

The 63027 features firm valving developed for medium to heavy load applications, ideal for owners who regularly carry gear or tow trailers. With 20.9-inch extended length and 12.9-inch compressed length providing 8 inches of travel, it's perfectly matched to work with 0-2 inch lift springs while maintaining proper suspension geometry. All mounting hardware and vehicle-specific bushings are included for direct bolt-on installation. Backed by a 3-year/35,000-mile warranty, this Australian-designed shock represents a comprehensive suspension upgrade for serious off-road enthusiasts.
