ARB OMELC08BP51H BP-51 Suspension Lift Kit Heavy Load for 2008-2024 Toyota Land

Vehicle Fitment

• 2008-2011, 2013-2021,2024 Toyota Land Cruiser 200 Series (4WD; 5.7L V8 3UR-FE; Base & Heritage Edition) - Full Suspension

Features

• Complete Old Man Emu heavy load suspension lift kit engineered for rugged overland and off-road use
• BP-51 bypass shock absorbers with remote reservoirs and adjustable damping for superior control
• Dual-valve bypass design provides position-sensitive damping for comfort and off-road performance
• Aerospace-grade 6061-T6 aluminum shock bodies with Type III hard-anodized finish for heat dissipation and corrosion resistance
• Front BP-51 coil-over shocks for improved wheel travel and front end control
• Heavy load-rated rear coil springs to support added vehicle weight and accessories
• No vehicle modification required - bolt-on installation with included fitment kits
• Adjustable rebound and compression for custom ride tuning across varied terrain

Specifications

• Application: Full front and rear suspension lift kit (heavy load)
• Lift Height: ~3.0 in front and rear over stock (approximate; varies with load and setup)
• Shock Design: BP-51 bypass shocks with remote reservoir
• Shock Material: 6061-T6 aluminum with Type III hard-anodized finish
• Front Shock Type: Internal bypass coil-over
• Rear Shock Type: Internal bypass with remote reservoir
• Mounts: Vehicle-specific front and rear fitment hardware included
• Adjustability: Rebound and compression tuning
• Warranty: ~3 years manufacturer warranty

Included Components

• 2x BP-51 front coil-over shock absorbers
• 2x BP-51 rear bypass shock absorbers
• 1x Heavy load rear coil spring set
• 1x Front fitment kit (vehicle mounts)
• 1x Rear fitment kit (vehicle mounts)

Product Description

The ARB OMELC08BP51H heavy load BP-51 suspension lift kit is a premium full system engineered specifically for the Toyota Land Cruiser 200 Series produced from 2008 to 2021. Designed to provide a substantial performance upgrade over the stock suspension, this kit blends cutting-edge bypass shock technology with robust coil springs tuned for added load. The BP-51 bypass shocks feature position-sensitive damping with remote reservoirs, allowing adjustable rebound and compression settings that help balance on-road comfort with controlled off-road articulation. This design delivers refined handling at highway speeds and confident control on rugged trails.

Constructed from aerospace-grade aluminum with a durable hard-anodized finish, the BP-51 shocks offer enhanced heat dissipation and corrosion resistance. The heavy load rear springs help support additional weight from accessories such as bumpers, roof gear, or camping equipment while maintaining ride height and stability. Installation is straightforward using vehicle-specific fitment kits, and no permanent modifications are required. The result is a 3-inch approximate suspension lift that improves ground clearance, tire clearance, and overall off-road capability. This kit is ideal for Land Cruiser owners seeking a complete suspension overhaul for demanding overland adventures and loaded conditions, and it includes a manufacturer warranty for confidence in long-term durability.
