ARB SJB36SFKIT Intensity Solis 36" Spot/Flood Light Kit w/Wiring - 18 178 Lumens

Vehicle Fitment

• Universal application--mountable on bumpers, roof racks, light bars, A-pillar brackets
• Suitable for trucks, SUVs, Jeeps, trailers, expedition vehicles

Fitment Notes

• Includes one spot and one flood light plus wiring harness--sold as a set
• Requires ARB pivot bracket or tube clamps (sold separately) for mounting
• Wiring harness enables 5-stage dimming via in-line touchpad
• Ideal as left/right pair; spot fires down-road, flood covers nearby terrain

Features

• 36 OSRAM LEDs (6x10 W + 30x4 W) delivers 18,178 lm raw output
• Spot beam reaches 1,032 m at 1 lux; flood covers 729 m at 1 lux
• Durable die-cast aluminum housing with active thermal dissipation
• UV-stable polycarbonate lens and powder-coated finish--IP68/IP69K rated
• Integrated thermal/RFI protection, GORE® breather, Deutsch connectors
• Security TORX mounting hardware included
• Operates on 10-30 V systems, draws 165 W (12.4 A @ 13.2 V)
• Backed by ARB's 3-year warranty; RoHS & Prop 65 compliant

Specifications

• Part Number: SJB36SFKIT
• Dimensions (each): 8.9" W x 8.7" H x 4.7" D
• Weight (each): 7.27 lb (3.3 kg); Kit w/ loom: ~25 lb packed
• Output: 18,178 lm raw; Effective: Spot 9,546 lm + Flood 8,333 lm
• Beam Pattern: Spot 6°, Flood 11°
• Lux @ 1 lux: Spot 1,032 m; Flood 729 m
• Operating Temp: -40 °F to +149 °F
• IP Rating: IP68/IP69K, RFI/EMC protected

Included Components

• 1x 36" Intensity Solis Spot light
• 1x 36" Intensity Solis Flood light
• 1x 5-stage dimming wiring harness with touchpad
• 2x Pivot-mount brackets with TORX hardware
• User manual and 3-year warranty leaflet

Product Description

The ARB SJB36SFKIT kit delivers a high-performance lighting solution combining one 36" Spot and one 36" Flood Intensity Solis light, complete with wiring harness. Together they generate a massive 18,178 raw lumens--ideal for off-road applications where both long-range clarity and wide terrain coverage are critical.

Housed in rugged die-cast aluminum with IP68/IP69K sealing and equipped with thermal management and secure Deutsch connections, these lights offer reliability in any environment. The included loom and dimming touchpad allow on-the-fly brightness adjustment. Perfect as a matched pair (spot left, flood right) for trucks, Jeeps, or expedition rigs that require adaptable, premium lighting performance.
