AMP Research 19-04279-XTA PowerStep Xtreme Replacement Controller 2008-25 Truck

Vehicle Fitment

• 2008-2025 Chevrolet and GMC trucks and SUVs equipped with AMP Research PowerStep Xtreme running boards (78xxx series kits) - see Fitment Notes for specific kit compatibility
• 2008-2025 Dodge/RAM trucks equipped with AMP Research PowerStep Xtreme running boards (78xxx series kits)
• 2008-2025 Ford trucks equipped with AMP Research PowerStep Xtreme running boards (78xxx series kits)
• Also compatible with kits 75135-01A, 77135-01A, and 76247-01A on supported vehicles

Fitment Notes

• This controller is exclusively for AMP Research PowerStep Xtreme applications - it is engineered for all four-motor PowerStep Xtreme configurations and is NOT compatible with standard PowerStep or PowerStep XL controllers
• Specifically compatible with: all 78xxx-series PowerStep Xtreme kits, plus kits 75135-01A, 77135-01A, and 76247-01A
• Does NOT work with PowerStep kits 75141-01A or 75134-01A - these kits require a different controller
• Compatible with AMP Research Optional Override Switches 79105-01A and 79106-01A - the additional plug on the controller is provided for this purpose
• Verify the exact AMP Research PowerStep Xtreme kit part number installed on your vehicle before ordering - if unsure, contact AMP Research / RealTruck support prior to purchase
• This product is non-returnable and non-refundable unless the part arrives defective - all sales are final
• New controllers can fit snugly on the main plug - ensure both clips are fully engaged and verify no pins are backing out of the original plug during installation

Features

• Replacement Xtreme-series controller (Type A, Revision 6) engineered specifically for AMP Research PowerStep Xtreme running boards running four-motor configurations - directly replaces a failed, damaged, or non-responsive original controller
• Restores automatic door-triggered PowerStep Xtreme deployment and retraction: steps extend when any door opens and retract after a 3-second delay when all doors close
• Designed for use across multiple vehicle makes and platforms - Chevrolet, GMC, Dodge/RAM, and Ford trucks equipped with compatible Xtreme-series kits
• Includes an additional connector plug for wiring in the optional AMP Research Override Switch (79105-01A or 79106-01A) to add manual step control capability
• Maintains compatibility with the PowerStep Xtreme dual-motor system's anti-pinch safety protection, which automatically stops motor movement if an obstruction is detected
• Black finish matches factory controller appearance

Specifications

• Part Type: Replacement electronic controller - PowerStep Xtreme series (Type A, Revision 6)
• Color: Black
• Controller Type: Xtreme (XTA) - not interchangeable with STA, STB, or SSA controller types
• Compatible PowerStep Series: PowerStep Xtreme (78xxx series), 75135-01A, 77135-01A, 76247-01A
• Incompatible Kits: 75141-01A, 75134-01A
• Override Switch Compatible: Yes - 79105-01A and 79106-01A
• Weight: 0.7 lbs.
• Package Dimensions: 7.5" L x 3.6" W x 3.5" H
• Returns: Non-returnable / non-refundable unless defective

Included Components

• 1x AMP Research PowerStep Xtreme replacement controller (Type A, Revision 6) with main harness plug and additional override switch plug
• Note: Wiring harness, running boards, motors, and mounting hardware are NOT included - this is a controller replacement part only
• Note: Optional Override Switch (79105-01A or 79106-01A) is NOT included - sold separately

Product Description

The AMP Research 19-04279-XTA is the Xtreme-series replacement controller (Type A, Revision 6) for AMP Research PowerStep Xtreme electric running boards. The PowerStep Xtreme is AMP Research's most capable running board line, designed specifically for demanding environments including sub-zero winters, mud-packed rockers, and extreme off-road conditions. Unlike the standard PowerStep's single-motor design, the PowerStep Xtreme uses a four-motor configuration requiring its own dedicated controller - and the 19-04279-XTA is the correct replacement when that controller fails due to electrical damage, corrosion, or age-related component failure. It is compatible with all 78xxx-series PowerStep Xtreme kits as well as kits 75135-01A, 77135-01A, and 76247-01A, spanning a wide range of 2008-2025 Chevrolet, GMC, Dodge/RAM, and Ford truck applications.

This controller replaces the original unit directly and restores full automatic operation: steps deploy when any door is opened and retract approximately 3 seconds after all doors are closed, with the dual-motor anti-pinch system remaining active to stop movement if an obstruction is detected. The controller includes a secondary connector plug dedicated to AMP Research's optional Override Switch (79105-01A or 79106-01A), which allows manual deployment or retraction - useful for washing, off-roading, or any situation where door-triggered automation is not desired.

Two important compatibility exclusions apply: the 19-04279-XTA does NOT work with PowerStep kits 75141-01A or 75134-01A, which require a different controller type. It is also not interchangeable with the STA, STB, or SSA controller variants used on standard PowerStep, PowerStep XL, or PowerStep Smart Series applications. During installation, note that the main plug connector can be snug - confirm both retaining clips are fully seated and check that none of the pins are backing out of the original plug before completing installation. Verify the exact PowerStep Xtreme kit part number installed on the vehicle before ordering. This is a final-sale replacement part - all purchases are non-returnable and non-refundable unless the controller arrives with a confirmed manufacturing defect.
