Air Lift 50256 Replacement Air Spring Sleeve for 04-15 Nissan Titan/16-23 Tacoma

Vehicle Fitment

• 2004-2015 Nissan Titan -- Rear
• 2016-2023 Toyota Tacoma 2WD/4WD -- Rear

Fitment Notes

• Replacement sleeve for Air Lift kit numbers: 59526, 59535, 59537, 59554, 59564 (Nissan Titan) and 75615 (Toyota Tacoma)
• Rear position only -- sold individually (one sleeve per unit)
• Order 2 for a complete rear axle replacement
• Hardware not included -- attaches to existing Air Lift brackets and airline

Features

• Exact replacement for original Air Lift air spring
• Sturdy rubber construction with synthetic fabric reinforcement
• Inverted crimp design -- helps air spring hold shape for extended life
• Genuine high-strength, rust-proof Zytel endcaps
• High-burst pressure rated
• Limited Lifetime Warranty

Specifications

• Part Number: 50256
• Type: Replacement sleeve (sleeve-type air spring)
• Position: Rear
• Compressed height: 2.4"
• Extended height: 6.8"
• Design ride height: 4.0"-6.0" inflated
• Maximum diameter: 5.1"
• Load capacity: 1,065 lbs at 100 PSI
• Inflation port size: 1/8"
• Mounting -- Side A: 3/4"-16
• Mounting -- Side B: 1/2"-13
• Hardware included: No
• Quantity: Sold individually
• Warranty: Limited Lifetime

Included Components

• 1x Replacement air spring sleeve

Product Description

The Air Lift 50256 is a replacement sleeve-type air spring for worn or damaged rear air bags on Air Lift Ride Control kits installed on the 2004-2015 Nissan Titan and 2016-2023 Toyota Tacoma. It is a direct replacement for the air spring included in Air Lift kit numbers 59526, 59535, 59537, 59554, 59564, and 75615 -- restoring the original load-leveling and ride-stabilizing function of the system at a fraction of the cost of replacing the full kit.

The sleeve is built from sturdy rubber with synthetic fabric reinforcement for burst resistance and durability. Genuine Zytel endcaps resist rust and corrosion, and an inverted crimp design keeps the air spring holding its shape over time. The design ride height of 4.0"-6.0" inflated covers the full operating range of the original kit, with a maximum diameter of 5.1" and a load capacity of 1,065 lbs at 100 PSI. Existing brackets and airline connect directly -- no new hardware required. Sold individually; order 2 for a complete rear axle. Backed by Air Lift's Limited Lifetime Warranty.
