Aeromotive 66172 ReturnX Return-Type PWM Controller Triple Pump Supercharged

Vehicle Fitment

• Universal - not vehicle-specific. Designed for stand-alone fuel systems using three brushed-type fuel pumps in a forced-induction setup

Fitment Notes

• For forced-induction (turbocharged/supercharged) applications only
• Developed for in-cell use where the primary output feeds a lift and pressure pump, with the secondary output driving the third pump
• Requires a return-style fuel system: plumb using traditional regulators, filters, and return lines

Features

• Stand-alone fuel pump speed control system for three brushed fuel pumps
• All pumps operate under PWM control for reduced heat and extended pump life
• Typical 45-75% reduction in power to the pumps during idle and cruise
• Includes a stand-alone 2.5 bar MAP sensor (LSA/LS9 type) with adequate range for supercharged applications
• Compatible with all brushed-type fuel pumps
• Reduces average fuel pump power requirement, lowering fuel temperatures
• Over-temperature shutdown with automatic reset
• Short-circuit output protection with automatic reset

Specifications

• Pump Configuration: Triple pump
• Application Type: Forced induction only
• Continuous Power Rating: 110A minimum
• MAP Sensor: 2.5 bar (LSA/LS9 type), included
• Connector Type: OEM Delphi/Aptiv-style

Included Components

• 1x ReturnX Return-Type Triple Pump PWM Controller
• 1x 2.5 Bar MAP Sensor and Mounting Hardware
• Wiring Harness with OEM-style Sealed Connectors

Product Description

The Aeromotive 66172 is a stand-alone ReturnX PWM controller built to drive three brushed fuel pumps in a forced-induction fuel system. It sits between Aeromotive's dual-pump and FourX controllers, giving builders a dedicated triple-pump option without stepping up to full four-pump hardware they don't need.

Like the rest of the ReturnX lineup, all three pumps run under PWM control, cutting power draw substantially during idle and cruise compared to running every pump at full duty cycle continuously. This is particularly valuable in high-horsepower boosted builds, where excess heat from running multiple pumps at full power can push the fuel system toward vapor lock, especially in a return-style setup where hot fuel cycles back through the tank.

This controller is designed for in-cell triple-pump installations - typically a lift/pressure pump on the primary output paired with a second pressure pump on the secondary - and is restricted to forced-induction use. It pairs with a traditional return-style regulator, filters, and return lines rather than a returnless setup.
