Aeromotive 15108 ORB-06 to AN-06 Port Fitting Kit (3 Pack) Regulator Fittings

Vehicle Fitment

• Universal - port fitting kit for Aeromotive fuel pressure regulators equipped with ORB-06 (O-ring boss -6) inlet, outlet, and return ports
• Compatible EFI regulators: Aeromotive PN 13109, 13138, 13129
• Compatible carbureted regulators: Aeromotive PN 13201, 13211, 13203, 13204, 13224
• Suitable for any application using Aeromotive ORB-06 port components where -6 AN braided stainless or PTFE fuel line connections are desired

Fitment Notes

• The 15108 kit contains three PN 15606 fittings - one for each of the three standard ORB-06 ports on a typical Aeromotive regulator (inlet, outlet, and return). For regulators with more than three ORB-06 ports (such as multi-inlet or multi-outlet designs), additional individual PN 15606 fittings may be required.
• These fittings convert the ORB-06 (O-ring boss) ports on the regulator to AN-06 male flare - for use with -6 AN swivel hose ends and AN-06 braided stainless or PTFE fuel line assemblies. Ensure that your fuel line hose ends are -6 AN female swivel (JIC 37-degree flare) for correct mating.
• This product is not legal for sale or use on emission-controlled vehicles except when used as a direct replacement part matching OEM specifications.

Features

• Three ORB-06 to AN-06 Male Flare Fittings (PN 15606 x 3): Each kit includes three of Aeromotive's PN 15606 straight ORB-06 to AN-06 male flare adapters - enough to outfit all three ports (inlet, outlet, and return) on a standard three-port Aeromotive regulator with -6 AN male connections for fuel line attachment.
• Maximum Flow Area - Long Radii for Smooth Transitions: Aeromotive's PN 15606 fittings are engineered with a maximum internal flow area and long internal radii for smooth transitions from the O-ring boss receiver to the AN flare outlet. This design eliminates the flow restriction and hydraulic cavitation that occurs at sharp-transition fittings - maintaining full fuel flow through the regulator connections without creating pressure drop at the fitting itself.
• CNC-Machined 6061 T6 Aircraft-Grade Aluminum - Type II Bright Dip Anodized Black: Each fitting is precision machined from 6061 T6 aircraft-grade billet aluminum and finished with Type II bright dip black anodizing - providing corrosion resistance against gasoline, ethanol, and methanol, and a clean black appearance that complements Aeromotive's black anodized regulator bodies.
• O-Ring Sealed ORB Connection - Positive Leak-Free Seal: The ORB (O-ring boss) receiver thread on each fitting mates with the ORB-06 machined ports on the Aeromotive regulator body - providing a positive, O-ring face seal connection that is inherently more leak-resistant than NPT tapered thread connections, which rely on thread deformation for sealing. The O-ring seal eliminates the risk of thread-form seal leakage under fuel system pressure cycling and vibration.
• Compatible with Gasoline and Alcohol Fuels: All materials - aluminum, anodizing, and O-ring seals - are fully compatible with pump gasoline, racing gasoline, ethanol (including E85), and methanol, covering the full range of fuel types used with Aeromotive regulators.
• Designed for Aeromotive Regulator Line Compatibility: The kit is expressly designed to provide the correct fitting specification for Aeromotive's family of ORB-06 port EFI and carbureted regulators (PN 13109, 13129, 13138, 13201, 13203, 13204, 13211, 13224) - eliminating the guesswork of sourcing correct AN-to-ORB adapters independently.

Specifications

• Part Number: 15108
• Brand: Aeromotive
• Product Type: ORB-06 to AN-06 Port Fitting Kit
• Contents: 3x Aeromotive PN 15606 (ORB-06 to AN-06 male flare fitting)
• Fitting Thread (Port Side): ORB-06 (O-ring boss -6)
• Fitting Connection (Line Side): AN-06 male flare (JIC 37°)
• Fitting Material: CNC-machined 6061 T6 aircraft-grade aluminum
• Fitting Finish: Type II bright dip anodized black
• Fuel Compatibility: Gasoline, Ethanol (E85), Methanol
• Compatible EFI Regulators: PN 13109, 13138, 13129
• Compatible Carbureted Regulators: PN 13201, 13211, 13203, 13204, 13224
• Weight: 0.2 lbs
• Fitment: Universal (by regulator compatibility)
• Emissions: Not legal for use on emission-controlled vehicles except as direct OEM replacement
• Warranty: 1 Year
• Quantity: 3 fittings per kit

Included Components

• 3x Aeromotive PN 15606 ORB-06 to AN-06 Male Flare Port Fitting (black anodized aluminum)

Product Description

The Aeromotive 15108 is a three-piece port fitting kit containing three PN 15606 ORB-06 to AN-06 male flare adapters - the correct fitting set to convert all three standard ORB-06 ports (inlet, outlet, and return) on Aeromotive's family of ORB-06 port EFI and carbureted fuel pressure regulators to -6 AN male flare connections for braided stainless or PTFE -6 AN fuel line attachment.

Each PN 15606 fitting is CNC-machined from 6061 T6 aircraft-grade aluminum with maximum internal flow area and long-radius internal transitions - eliminating the hydraulic cavitation and flow restriction that occurs at sharp-transition fittings, and providing a positive O-ring sealed connection that outperforms NPT thread sealing in pressure cycling and vibration environments. Type II bright dip black anodized finish. Compatible with gasoline, E85, and methanol. Not for emission-controlled vehicles. Universal fitment by regulator compatibility. 1-year warranty.
