ACT 3000502 Performance Street Sprung Clutch Disc 228mm 1991-2018 Subaru WRX STI

Vehicle Fitment

• 1991-1999 Subaru Legacy (2.2L Turbo / 2.5L Turbo)
• 1993-2001 Subaru Impreza (2.0L / 2.2L, incl. WRX / STI Turbo)
• 2002-2005 Subaru Impreza WRX / STI (2.0L / 2.5L Turbo)
• 2004-2005 Subaru Forester XT (2.5L Turbo)
• 2004-2005 Subaru Baja Turbo (2.5L Turbo)
• 2005 Saab 9-2X Aero (2.0L Turbo)
• 2006-2014 Subaru Impreza WRX (2.5L EJ255)
• 2015-2018 Subaru WRX (2.0L FA20F -- pre-VIN J806877)
• 2006-2012 Subaru Legacy GT / Outback XT (2.5L Turbo)
• 2007 Subaru Impreza WRX STI [JDM] (2.5L Turbo)

Fitment Notes

• Disc only -- sold individually (no pressure plate, bearing, or hardware)
• Does NOT fit 2018+ WRX with VIN J806877 or later -- those use 240mm clutch components
• Does NOT fit 2015+ WRX STI -- different disc diameter
• Spline: 1.0 inch x 24-spline
• 300-500 mile street break-in recommended before aggressive use
• SFI 1.1 certified

Features

• Premium organic friction -- high copper content for heat transfer
• Steel-backed linings -- greater burst strength and durability
• Reduced marcel -- faster shift action
• Spring-centered hub -- frictional dampening for smooth, quiet operation
• Heat-treated wraparound spring windows -- reduced stress concentrations
• Computer spin balanced to within .25 oz-in
• SFI 1.1 certified
• 1-year warranty

Specifications

• Part Number: 3000502
• Disc Type: Performance Street Sprung (organic)
• Diameter: 228mm (9 inches)
• Spline: 1.0 inch x 24-spline
• Disc Material: Organic composite
• Weight: 3.4 lbs
• SFI: 1.1
• UPC: 00842385030322
• Warranty: 12 months
• Quantity: Sold individually

Included Components

• 1x ACT Performance Street Sprung clutch disc

Product Description

The ACT 3000502 is the Performance Street Sprung clutch disc -- ACT's most popular disc -- engineered for Subaru turbo applications from 1991 through 2018. Compatible with Subaru Legacy, Impreza WRX/STI, Forester XT, Baja Turbo, and the Saab 9-2X Aero (which shares the WRX platform), this 228mm disc features premium organic friction material with high copper content for superior heat transfer and steel-backed linings for greater burst strength. The spring-centered hub uses bushings and cone springs to create frictional dampening -- reducing noise and extending clutch life while maintaining a smooth, progressive engagement feel.

This is a disc-only part -- it does not include a pressure plate, throwout bearing, or alignment tool. Note that 2018 WRX models with VIN J806877 or later were converted to 240mm clutch components at the factory and are not compatible with this disc. SFI 1.1 certified. Allow 300-500 miles of gentle city driving break-in before spirited or track use. Backed by ACT's 1-year warranty.
