TiALSport 002954 MV-S 38mm External Wastegate 1.75" Universal Purple V-Band

Vehicle Fitment

• Universal -- non application-specific, verify compatibility with your turbo system before purchase

Fitment Notes

• Not vehicle-specific -- fitment depends on turbo system layout and mounting
• May require some modification for proper installation
• V-band mounting, no factory wastegate flange required

Features

• Compact 3.7" height, more compact than the F38 predecessor
• V-flanged design for flexible fabrication and installation
• High-temp alloy valve construction
• Stainless steel valve housing for extended product life
• High-temperature silicone-reinforced actuator diaphragm
• Stainless steel actuator spring for consistent high-temperature pressure
• Stainless steel valve seat and valve bushing
• All stainless steel hardware
• 304L mating weld flanges
• 3 lower ports and 2 top air signal ports, no actuator rotation needed for install
• Plugs included for unused ports

Specifications

• Series: MV-S
• Valve size: 38mm
• Inlet flange: 1.75" OD
• Outlet flange: 1.50" OD
• Height: 3.7"
• Pressure range: 0.3-1.7 BAR
• Finish: Purple anodized

Included Components

• 1x MV-S wastegate
• 1x Full set of actuator springs
• 1x Set of V-band clamps
• Port plugs for unused ports

Product Description

The TiALSport 002954 MV-S is a 38mm external wastegate engineered for precise boost control on turbocharged builds, standing just 3.7" tall -- significantly more compact than its F38 predecessor. The V-flanged design gives builders far more flexibility for fabrication and mounting compared to a traditional flange-style wastegate, making it easier to package in tight engine bays.

Built with a high-temp alloy valve and stainless steel valve housing, this wastegate is engineered for a longer service life than competing designs. A high-temperature silicone-reinforced actuator diaphragm and stainless steel actuator spring maintain consistent boost control pressure even under sustained high heat, while stainless steel hardware throughout resists corrosion in the engine bay.

With 3 lower ports and 2 top air signal ports, this wastegate installs without ever needing to rotate the actuator top to line up plumbing -- unused ports ship with plugs included. The kit includes the full range of actuator springs for 0.3-1.7
