BorgWarner 13009097008 S300 SX-E Super-Core Turbo 64.5mm/76mm FMW, 68mm Turbine

Vehicle Fitment

• Universal Fit (S300 SX-E Super-Core only; turbine housing sold separately)

Features

• S300 SX-E (aka S364.5 SX-E 8776) Super-Core assembly - cartridge + compressor cover
• Forged-milled compressor wheel with Extended Tip Technology - based on EFR8776 design
• 360° thrust bearing for enhanced durability under high boost
• Integrated speed sensor port and pre-machined boost reference port
• Optimized compressor stage aerodynamics for improved flow
• Straight compressor discharge with flexible outlet options (coupler or V-band)
• Interchangeable with existing AirWerks turbine housings
• Twin hydrodynamic journal bearings for robust oil flow support

Specifications

• Compressor wheel inducer: 64.47 mm; exducer (wheel OD): 87.37 mm
• Turbine wheel outer diameter: 76.20 mm; exducer: 67.56 mm
• Max estimated flow: ~82 lb/min (approx. 820 flywheel HP)
• Compressor housing inlet: 4.0" hose coupler; outlet: 2.5" standard or V-band options
• Bearing housing: oil-cooled, journal bearing with 360° thrust assembly
• Does not include turbine housing, speed sensor, drain port fitting, or V-band

Included Components

• 1x Super-Core cartridge assembly (compressor cover, compressor wheel, turbine wheel, bearing housing)
• Mounting hardware: clamp plates, cap screws, gaskets

Product Description

The BorgWarner 13009097008 S300 SX-E Super-Core Turbo (also referred to as the S364.5 SX-E 8776) offers a high-performance cartridge setup for tuners and builders. Its FMW (forged-milled) 64.47 mm inducer compressor wheel - derived from the EFR8776 design and paired with Extended Tip Technology - provides exceptional airflow (≈ 82 lb/min or ~820 HP), while the robust 76.20 mm turbine wheel ensures efficient energy extraction. The integrated 360° thrust bearing delivers strength and longevity even under aggressive boost.

Designed for flexibility, this Super-Core includes essential hardware but omits the turbine housing, allowing selection of your preferred T3/T4 or twin-scroll housing for customized spool and fitment. It features a straight compressor outlet, multiple outlet interface options (coupler or V-band), plus pre-machined ports for boost and speed sensor integration - making installation and tuning a streamlined process.
