Garrett 836026-5013S -GT2860RS Dual Ball Bearing Turbocharger 0.86 A/R

Vehicle Fitment

• Universal turbocharger: designed for 1.8-3.0 L engines using T25 flange, internally wastegated GT2860RS platform

Fitment Notes

• Turbocharger is not specific to any OEM vehicle - fits custom installations or engine swaps with appropriate manifold and oil/coolant plumbing
• Includes internal wastegate actuator; requires 5-bolt T25 turbine flange
• Not CARB legal; intended for tuning or race applications

Features

• 47 mm compressor inducer and 60 mm exducer with 62-trim compressor wheel (GT Series aerodynamics)
• 54 mm turbine inducer, 47 mm exducer with 76-trim turbine wheel in 0.86 A/R housing
• Ball bearing CHRA with oil and water cooling for faster spool and durability
• Supports output equivalent of ~250-360 hp depending on setup
• Includes compressor housing, turbine housing, CHRA, actuator, and hardware
• V-band options available for custom installations
• High-performance Garrett design with lifetime support from authorized vendors
• Designed for drag, road racing, and performance engine builds

Specifications

• Part No.: 836026-5013S (0.86 A/R T25 turbine housing)
• Compressor Wheel: 47/60 mm, trim 62
• Turbine Wheel: 54/47 mm, trim 76
• Compressor Housing A/R: 0.60
• Turbine Housing A/R: 0.86
• CHRA: Dual ceramic ball bearing, oil & water cooled
• Recommended Power Range: 250-360 hp
• Warranty: From Garrett via authorized distributors

Included Components

• Complete GT2860RS turbocharger assembly (CHRA, compressor & turbine housing, actuator)
• Factory-matched hardware for installation
• Gaskets and V-band option (if selected)
• Instructions and support documentation

Product Description

The Garrett GT2860RS turbocharger (part 836026-5013S) is a dual ball-bearing, internally wastegated unit designed for high-performance applications in the 250-360 hp range. Featuring Garrett's GT-series compressor and turbine aerodynamics, this turbo offers fast spool response, improved durability, and precise boost control suitable for custom installations and engine swaps using 1.8-3.0 L powerplants.

Equipped with a 47 mm/60 mm compressor and 54 mm/47 mm turbine wheel with 0.86 A/R housing, this turbo supports aggressive duties and comes standard with oil and water cooling to maintain consistent operating temperatures. It includes all necessary components - including actuator and hardware - ready for build integration with properly configured manifolds and plumbing.

As a universal performance component, the GT2860RS is not vehicle-specific or emissions-certified. It is intended for off-road, motorsport, or custom engine installations. Please ensure compatibility with your intake and exhaust configuration before purchase.
