Garrett 953223-5001S PowerMax Turbocharger 250BHP +26% for 09-23 Fiat 500 Abarth

Vehicle Fitment

• 2009-2023 Fiat 500 Abarth (1.4L I4 Turbo)

Fitment Notes

• Direct replacement for Garrett OEM PN 55275806 / 812812-5006S
• Complete turbocharger assembly -- calibrated actuator included
• Turbo speed sensor port machined -- sensor sold separately
• Compatible speed sensors: G-Smart 923586-0002 / Street Kit 781328-0001 / Pro Kit 781328-0002
• Maximum allowable shaft speed: 240,000 RPM -- use speed sensor when operating at high performance levels
• ECU tuning/calibration may be required to achieve full power capability
• Not street legal -- for racing and track use only per Garrett guidelines

Features

• Supports up to 250 BHP / 186 kW (+26% compressor flow vs. OEM)
• Direct-fit -- no custom fabrication required
• Matches OEM mounting, oil/coolant connections, and intake/exhaust interfaces
• Calibrated actuator included in assembly
• Fully machined turbo speed sensor port
• OEM-level durability and quality standards
• 70+ years of Garrett turbocharger engineering
• 130+ million vehicles powered globally

Specifications

• Turbo Model: MGT1446Z
• Engine: 1.4L I4 Turbo
• Power Capability: 250 BHP / 186 kW
• Compressor Flow Increase: +26% vs. OEM
• Compressor Inducer: 36.2mm
• Compressor Exducer: 46mm
• Turbine Inducer: 39mm
• Turbine Exducer: 34mm
• Max Shaft Speed: 240,000 RPM
• Replaces OEM PN: 55275806 / 812812-5006S

Included Components

• 1x MGT1446Z PowerMax turbocharger assembly
• 1x Calibrated actuator (pre-installed)

Product Description

The Garrett 953223-5001S PowerMax is a direct-fit performance turbocharger engineered for the 2009-2023 Fiat 500 Abarth 1.4L I4. It replaces the factory Garrett turbo (OEM PN 55275806 / 812812-5006S) with a performance-upgraded MGT1446Z assembly that delivers a +26% increase in compressor flow over the OEM unit, supporting up to 250 BHP / 186 kW capability. The PowerMax bolts directly to the factory mounting locations and reuses the OEM oil and coolant connections, intake and exhaust interfaces, and factory actuator mounting -- no custom fabrication or adapter hardware is required. A calibrated actuator is included in the complete assembly. The turbocharger features a fully machined shaft speed sensor port, allowing optional installation of a turbo speed monitoring system to protect against overspeed -- particularly important when operating at higher performance levels. Maximum allowable shaft speed is 240,000 RPM, and exceeding this limit is at the owner's risk. Compatible speed sensor options include the G-Smart Bluetooth Module (923586-0002), the Street Kit with gauge (781328-0001), and the Pro Kit without gauge (781328-0002), all sold separately. ECU calibration or tuning may be required to achieve the full stated power capability, as horsepower figures are based on laboratory compressor flow testing. Important: per Garrett's official product guidelines, the PowerMax is a professional aftermarket product intended exclusively for racing vehicles operated on closed race tracks. It is not legal for use on public roads and may void vehicle warranty, operating license, or type approval. Installation and use are entirely at the owner's risk and responsibility.
