BorgWarner 177281 S300SX3 S366 Turbocharger - 66mm Inducer, .88 A/R T4, Universa

Vehicle Fitment

• Universal Fit - Suitable for custom applications across various engine configurations

Features

• 66mm extended tip compressor wheel enhances airflow and efficiency
• 80mm turbine wheel with 73mm exducer for optimal exhaust flow
• .88 A/R T4 open flow turbine housing for balanced performance
• Twin hydrodynamic journal bearings ensure durability and reliability
• Adjustable compressor and turbine housing orientation for flexible installation
• Oil-cooled bearing housing with 1/4" NPT oil inlet and 3/8-16 threaded oil drain
• Compressor cover features recirculation grooves to reduce surge
• Supports power outputs ranging from 500 to 830 horsepower

Specifications

• Part Number: 177281
• Turbo Model: S300SX3 (S366)
• Compressor Wheel Inducer Diameter: 66 mm (2.60 inches)
• Compressor Wheel Outer Diameter: 91.4 mm (3.60 inches)
• Turbine Wheel Inducer Diameter: 80 mm (3.14 inches)
• Turbine Wheel Exducer Diameter: 73 mm (2.89 inches)
• Turbine Housing A/R: .88
• Flange Type: T4 Open
• Compressor Outlet: 4.21" Hose Style
• Oil Inlet: 1/4" NPT
• Oil Drain: 3/8-16 Threaded
• Cooling: Oil-Cooled Only
• Country of Origin: USA

Included Components

• BorgWarner 177281 S300SX3 S366 Turbocharger
• Gasket set for installation
• Installation instructions

Product Description

The BorgWarner 177281 S300SX3 S366 Turbocharger is a high-performance, universal-fit turbo designed for enthusiasts seeking significant power gains. Featuring a 66mm extended tip compressor wheel and a .88 A/R T4 open flow turbine housing, this turbocharger delivers exceptional airflow and efficiency, supporting power outputs between 500 and 830 horsepower.

Its twin hydrodynamic journal bearings ensure durability under high-stress conditions, while the adjustable compressor and turbine housing orientation allows for flexible installation across various custom applications. The oil-cooled bearing housing, equipped with a 1/4" NPT oil inlet and 3/8-16 threaded oil drain, ensures optimal lubrication and cooling.

Whether you're building a high-powered street machine or a dedicated race car, the BorgWarner 177281 S300SX3 S366 Turbocharger offers the performance and reliability needed to achieve your goals.
