Torque Solution TS-TH-SDPC Driveshaft Carrier Drop Spacer Kit for 05-21 Subaru

Vehicle Fitment

• 2008-2021 Subaru Impreza WRX/STI (GR/GV/VA Chassis, 2.5L H4 Turbo) AWD
• 2009-2018 Subaru Forester (SH/SJ Chassis, All Engines) AWD
• 2005-2014 Subaru Legacy/Outback (BL/BP/BM/BR Chassis, All Engines) AWD
• 2008-2011 Subaru Impreza (GH/GE Chassis, All Engines) AWD

Fitment Notes

• Designed to correct driveshaft geometry following the installation of suspension lift or lowering kits.
• Fits sedan and wagon/hatchback variants of the applicable chassis codes.
• Requires sufficient clearance for the new carrier bearing mounting position.

Features

• Eliminates or significantly reduces driveshaft vibration following suspension modifications.
• Precision CNC machined from high-strength billet 6061-T6 aluminum.
• Anodized finish for superior corrosion resistance and longevity.
• Specifically engineered to maintain optimal U-joint and CV-joint operating angles.
• Direct bolt-on installation using factory mounting points.
• Maintains proper driveshaft alignment under high-load conditions.
• Ideal for vehicles with 1.0" to 2.5" of lift or moderate lowering.
• Includes all necessary high-grade, corrosion-resistant installation hardware.

Specifications

• Material: CNC Billet 6061-T6 Aluminum
• Drop Specification: 10mm (0.39 inches)
• Hardware: Grade 8 Zinc-Plated Installation Bolts
• Position: Driveshaft Carrier Bearing Mounting Location (Mid-Chassis)
• Weight: Approximately 0.5 lbs

Included Components

• 2x Torque Solution Carrier Bearing Drop Spacers (10mm)
• 4x Grade 8 Mounting Bolts
• 4x Grade 8 Locking Nuts
• 4x Grade 8 Washers

Product Description

The Torque Solution Driveshaft Carrier Bearing Drop Spacer Kit (TS-TH-SDPC) is an essential component for any Subaru owner who has modified their vehicle's suspension geometry, whether through a performance lowering kit or a lift kit. Changes in ride height - even minor ones - alter the driveshaft's operating angle relative to the rear differential and transmission. This angular misalignment creates driveline harmonics, which manifest as an irritating shudder, rumble, or vibration, particularly noticeable during acceleration and high-speed cruising.

This kit directly addresses the issue by lowering the carrier bearing mount by a precise 10mm. This adjustment is specifically calibrated to restore the driveshaft's pinion angle back into its acceptable, factory-like operating range. By correcting this angle, the spacers effectively eliminate or significantly reduce the unwanted vibrations, dramatically improving driving comfort and protecting sensitive drivetrain components.

Manufactured from robust 6061-T6 billet aluminum and precision CNC machined for a perfect fit, these spacers install directly into the factory location with the included high-grade Grade 8 hardware. This simple, bolt-on solution is critical for maintaining the longevity of your driveshaft U-joints and carrier bearing, making it a mandatory upgrade when adjusting the suspension on applicable Subaru chassis like the popular GR/GV/VA WRX and STI platforms.
