BorgWarner 13009097006 S363 SX-E Super-Core 63/68 2.48" Inducer Universal

Vehicle Fitment

• Universal (super-core; fits various custom turbo applications)

Features

• AirWerks SX-E Super-Core design (no turbine housing included)
• Forged-milled 63 mm compressor inducer with 87.37 mm exducer (FMW billet wheel)
• Robust 76.20 mm turbine wheel for high flow
• 360° thrust bearing for durability under high boost
• Compressor cover pre-tapped for speed sensor and boost reference port
• Flexible compressor outlet options (factory 2.5" port, add-on V-band optional)
• Optimized compressor cover aerodynamics for improved efficiency
• Compatible with a wide range of turbine housings for adaptability

Specifications

• Compressor inducer: 62.99 mm (2.48")
• Compressor exducer: 87.37 mm (3.44")
• Turbine wheel: inducer ~80 mm, exducer 76.20 mm (3.00")
• Series: S363 (also S300 SX-E family)
• Bearing type: 360° hydrodynamic thrust bearing assembly
• Weight flow: approximately 78 lbs/min (~785 flywheel HP)
• Inlet: 4" / Outlet: 2.5" (factory), optional V-band available
• Note: turbine housing, speed sensor, and V-band not included

Included Components

• 1x compressor cover with cartridge assembly
• 1x bearing housing assembly (shaft, bearings, thrust system)
• Mounting hardware: clamp plates, cap screws, mounting gaskets

Product Description

The BorgWarner 13009097006 AirWerks S363 SX-E Super-Core is a high-performance turbo core built for custom and high-boost applications. Featuring a forged-milled compressor wheel with a 62.99 mm inducer and 87.37 mm exducer, paired with a robust 76.20 mm turbine wheel, this assembly delivers rapid spool and exceptional flow. The integrated 360° thrust bearing ensures reliability during sustained high-pressure operation, and the pre-tapped compressor cover simplifies sensor and boost line integration.

As a super-core unit, the 13009097006 provides unmatched flexibility - builders can select turbine housings tailored to their setup requirements. The kit includes all mounting hardware, though turbine housing, V-band outlet, and speed sensor are not provided and must be selected separately. Ideal for both gasoline and diesel performance engines, it supports approximately 785 HP (flywheel) when configured correctly. Trust in BorgWarner's proven SX-E platform for your next serious build.
