ARP 206-4201 Head Stud Kit for 1959-1980 Austin Mini/Morris Minor/MG Midget 948

Vehicle Fitment

• BMC/Triumph A-Series Engine Applications (9-Stud Head Pattern)

Fitment Notes

• Fits BMC/Triumph A-Series engines with 9-stud head bolt pattern
• Common applications include Austin-Healey Sprite, MG Midget, Morris Minor, Mini, and other A-Series powered vehicles
• Verify stud count and pattern for your specific A-Series application
• Use ARP Ultra-Torque assembly lubricant (ARP 100-9909, sold separately) for accurate torque readings
• Sold as a complete kit

Features

• ARP Pro Series cylinder head stud kit
• Premium 8740 chromoly steel -- heat-treated to 200,000 PSI
• Cold-forged for molecular integrity
• Thread rolled after heat-treat -- 2,000% better fatigue strength
• Centerless ground for precise concentricity and alignment
• 12-point nuts for easy installation in tight spaces
• Hardened parallel washers for even load distribution
• Black oxide finish for corrosion resistance
• ARP stamped on each stud for authenticity
• Made in USA (Ventura, CA)

Specifications

• Type: Cylinder Head Stud Kit
• Engine Application: BMC/Triumph A-Series
• Stud Count: 9
• Material: 8740 Chromoly Steel
• Tensile Strength: 200,000 PSI
• Nut Style: 12-Point
• Finish: Black Oxide
• Undercut: No
• Washers Included: Yes (Hardened Parallel)
• UPC: 672036007966
• Made In: USA

Included Components

• 9x ARP Pro Series 8740 chromoly head studs
• 9x 12-point nuts
• 9x Hardened parallel washers

Product Description

The ARP 206-4201 is a Pro Series cylinder head stud kit for BMC/Triumph A-Series engines with a 9-stud head bolt pattern. ARP Pro Series head studs are the gold standard for engine builders -- virtually every top professional engine builder relies on ARP for their competition powerplants, and for good reason. ARP uses only premium-grade 8740 chromoly alloy steel rated far superior to standard "aircraft quality" alloy steels. Each stud is cold-forged for molecular integrity, then heat-treated to 200,000 PSI using a precise vertical racking process that ensures complete and uniform heat penetration -- far superior to the basket heat-treat methods used by lesser manufacturers.

Following heat-treat, each stud is centerless ground through approximately ten very slight cuts to achieve near-perfect concentricity -- allowing gaskets and cylinder heads to glide into position with perfect alignment. Critically, ARP threads are rolled after heat-treat, which delivers approximately 2,000% better fatigue strength than studs threaded before heat-treat, a common cost-cutting industry practice. The kit includes 12-point nuts for easy installation access in tight engine bay spaces and hardened parallel washers that ensure even load distribution and accurate torque readings across all nine studs. This consistent clamping force helps prevent blown head gaskets and assures optimum engine sealing. Look for the ARP stamp on each stud as your assurance of authenticity and quality. Made in Ventura, California, USA.
