Radium 20-0503-PK Fuel Rail Plumbing Kit for Mazda NC MX-5 Ford Focus Duratec

Vehicle Fitment

• 2005-2015 Mazda MX-5 Miata (NC Chassis, 2.0L MZR DOHC I4, RWD)
• 2001-2011 Ford Focus (2.0L Duratec DOHC I4, FWD)
• 2001-2007 Ford Focus (2.3L Duratec DOHC I4, FWD)
• 2001-2011 Ford Ranger (2.3L Duratec DOHC I4, RWD/4WD)
• 2001-2007 Mazda B-Series (2.3L MZR DOHC I4, RWD/4WD)

Fitment Notes

• This is a plumbing-only kit - the fuel rail (Radium 20-0503-02) must be purchased separately
• Not compatible with direct-injected (GDI/DI) engine variants
• Early Ford models with a Bosch fuel pressure sensor on the OEM fuel rail require the separate Radium 20-1303 Ford Sensor Adapter (fits 2005-2009 Ford Focus and 2005-2008 Ford Escape)
• Compatible with OEM or OEM-equivalent injectors only; injector height and O-ring dimensions must match factory specs
• For use with the Radium 20-0503-02 fuel rail only

Features

• Provides all necessary adapters to make the 20-0503-02 fuel rail a direct OEM replacement
• 8AN ORB port configuration allows flexible plumbing and accessory mounting
• Compatible with all fuel types including E85 and other alcohol blends
• Eliminates the need for custom fabrication - bolt-in plumbing solution
• Designed and manufactured in the USA by Radium Engineering
• Works with the standard 8AN ORB fittings used across Radium's fuel system product line

Specifications

• Port Size: 8AN ORB (3/4"-16)
• Fitting Type: SAE and ORB plug adapters
• Application: Plumbing kit for Radium 20-0503-02 fuel rail
• Fuel Compatibility: Gasoline, E85, and alcohol-blend fuels
• Engine Type: Port-injected (non-direct-injected) MZR/Duratec DOHC I4 only

Included Components

• 2x 8AN ORB Plugs
• 1x 8AN ORB SAE Fitting

Product Description

The Radium Engineering 20-0503-PK is the dedicated plumbing kit for the Radium 20-0503-02 fuel rail, designed for port-injected Mazda MZR and Ford Duratec 4-cylinder engines. It includes the 8AN ORB plugs and SAE fitting needed to connect the aftermarket rail directly to the factory fuel system, making the upgrade a clean, bolt-in installation without any custom fabrication.

Fully compatible with E85 and other alcohol-blend fuels, this kit integrates seamlessly with Radium's broader fuel system ecosystem, including their direct-mount regulators, fuel pulse dampers, and fuel pressure gauge adapters. Note that early Ford Duratec engines equipped with a Bosch fuel pressure sensor require the separate Radium 20-1303 sensor adapter; the fuel rail itself (20-0503-02) is sold separately.
