Ticon 103-08910-0010 3.5in Titanium 2-Bolt Flange .375 Thick CP2

Vehicle Fitment

• Universal Fabrication Component. Designed for welding to any 3.5-inch O.D. pipe to create a secure, removable, high-temperature, 2-bolt exhaust connection point.

Fitment Notes

• Requires professional TIG welding for integration. Argon back-purging is mandatory when welding Grade 2 (CP2) Titanium to prevent oxidation and ensure a strong weld.
• Must be paired with a corresponding 3.5-inch, 2-bolt flange of the same bolt spacing and gasket style for a proper seal.
• The 3/8-inch thickness provides maximum rigidity for a leak-free seal under high-heat and high-vibration conditions.

Features

• Constructed from durable, high-strength Commercially Pure Grade 2 (CP2) Titanium.
• Precision-cut 3.5-inch opening is perfectly sized for 3.5-inch O.D. titanium tubing to minimize fitment gap.
• Thick 0.375-inch (3/8") material prevents warping and ensures a flat mating surface for reliable gasketing, even under extreme thermal load.
• Titanium offers a substantial weight reduction over traditional stainless or mild steel flanges of the same size.
• Ideal for custom large-diameter exhaust, downpipes, and intake components where weight savings are critical.
• CP2 Titanium provides excellent weldability and maintains structural integrity in extreme exhaust temperature environments.
• 2-bolt pattern is a common standard, allowing for broad compatibility with various exhaust setups.

Specifications

• Part Position: Universal Exhaust Flange
• Material: Commercially Pure Grade 2 (CP2) Titanium
• Nominal Pipe Size: 3.5 inches (88.9mm)
• Thickness: 0.375 inches (3/8 inch)
• Bolt Pattern: 2-Bolt
• Installation: Weld-On (Requires TIG Welding)

Included Components

• 1x 3.5" O.D. x 3/8" Thick 2-Bolt Titanium Flange

Product Description

The Ticon Industries 103-08910-0010 Titanium 2-Bolt Flange is an essential component for fabricators creating high-end, large-diameter, lightweight exhaust and piping systems. This flange is precision-machined from Commercially Pure Grade 2 (CP2) Titanium, a material specifically chosen for its superior strength, high-temperature resistance, and excellent weldability. The substantial 0.375-inch (3/8") thickness is crucial for preventing warping and ensuring a consistently leak-free seal when mated to a corresponding flange under the extreme thermal cycles of a performance system.

Designed to weld directly onto 3.5-inch O.D. piping, this flange provides a robust, removable connection point while delivering massive weight savings compared to conventional steel flanges. **For proper installation, professional TIG welding with mandatory argon back-purging** is required to fuse the flange to the titanium piping, ensuring the highest possible weld quality and material longevity. The standard 2-bolt configuration allows for easy integration into a wide variety of custom or existing exhaust setups.
