Skunk2 305-05-0140 Tuner Series Stage 1 Camshaft Set for 1992-2001 Honda/Acura B

Vehicle Fitment

• 1992-2001 Acura Integra GS-R / Type R (B17A1, B18C1, B18C5) - 1.7/1.8L DOHC VTEC
• 1994-2001 Honda Civic Si / del Sol VTEC 1.6L (B16A) - 1999-2000 Civic Si specified

Features

• Stage 1 camshaft set designed for mild performance builds on B-series VTEC engines
• Optimised lift/duration for improved horsepower (approx. +10-15 hp) and torque (+12-16 lb-ft)
• Designed to retain factory idle and low-speed emissions when installed
• Compatible with stock valve springs and retainers (no major valvetrain upgrade required)
• Ground via CNC machines with hardened, wear-resistant lobes for durability
• Designed for 1,500-8,500 rpm usable range
• Map your ECU and supporting intake/exhaust to fully exploit the profile
• CARB exempt only in certain applications (check local regulations) and not legal in all regions

Specifications

• Part Number: 305-05-0140
• Intake lift: ~11.5 mm (0.452")
• Exhaust lift: ~10.8 mm (0.425")
• Duration at 0.050" lift: Intake ~251°; Exhaust ~252°
• Intake centreline: 96° ATDC; Exhaust centreline: 99° BTDC
• Valve clearance (as specified): Intake .007"; Exhaust .008"
• Engine compatibility: Honda/Acura B-series DOHC VTEC (B16A, B17A1, B18C1, B18C5)
• Emissions: Not legal for sale or use in California on pollution-controlled motor vehicles (for some markets) - check your region

Included Components

• 1x Intake camshaft (Stage 1 profile)
• 1x Exhaust camshaft (Stage 1 profile)
• Hardware packet (if supplied by manufacturer) - shims/spacers as required

Product Description

The Skunk2 Tuner Series Stage 1 Camshaft Set (part 305-05-0140) is engineered for Honda/Acura enthusiasts running B-series DOHC VTEC engines (1.6L-1.8L) who seek a performance upgrade without sacrificing drivability. With a modest lift and duration increase, the set offers approximately 10-15 hp gain and improved torque in the mid to upper rpm range, while retaining a factory-like idle and reliable valvetrain compatibility.

Manufactured from high-quality materials with precise CNC grinding and hardened lobes, these camshafts are built for longevity and performance. They are rated for a broad rpm range (approx. 1,500-8,500 rpm) and are well suited to mildly modified naturally-aspirated or lightly boosted B-series VTEC builds. Installation is straightforward with stock springs and retainers in many cases - but proper tuning of ECU, intake, and exhaust is highly recommended for best outcomes.

Fitment is confirmed for the listed years and models above. **Fitment confirmed through 2001. 2025 coverage unconfirmed at time of listing.** If you are running a specific JDM variant, swap-engine or non-VTEC configuration, confirm compatibility accordingly.
