COMP Cams113400 Xtreme Energy 222/224 Hydraulic Roller Cam for 2001-2010 GM

Vehicle Fitment

• Chevrolet Cavalier 2002-2005 (2.2 L Ecotec I4)
• Chevrolet Classic 2004-2005 (2.2 L Ecotec I4)
• Chevrolet Cobalt 2005-2010 (2.2 L Ecotec I4)
• Chevrolet HHR 2006-2011 (2.2 L Ecotec I4)
• Chevrolet Malibu 2004-2008 (2.2 L Ecotec I4)
• Oldsmobile Alero 2002-2004 (2.2 L Ecotec I4)
• Pontiac G5 2007-2010 (2.2 L Ecotec I4)
• Pontiac Grand Am 2002-2005 (2.2 L Ecotec I4)
• Pontiac Sunfire 2002-2005 (2.2 L Ecotec I4)
• Saturn Ion 2003-2007 (2.2 L Ecotec I4)
• Saturn L100 / L200 / L300 2001-2004 (2.2 L Ecotec I4)
• Saturn LS / LW1 / LW200 2000-2003 (2.2 L Ecotec I4)
• Saturn Vue 2006-2007 (2.2 L Ecotec I4)

Features

• Xtreme Energy series - high-performance hydraulic roller cam
• Hydraulic roller design for smooth operation and durability
• High RPM range: 3,500-8,000 rpm
• Aggressive lobe profiles for strong top-end power
• Optimized mid-range torque for street and strip applications
• Increases vacuum to improve power brake performance
• Compatible with supporting upgrades: intake manifold, headers, ECU tuning
• Cast-core design balances strength and affordability

Specifications

• Part Number: 113400
• Grind / Model: XE264HR-13
• Operating RPM Range: 3,500-8,000 rpm
• Advertised Duration: 264° intake / 268° exhaust
• .050" Duration: 222° intake / 224° exhaust
• Valve Lift: 0.456" intake / 0.453" exhaust
• Lobe Separation Angle (LSA): 113°
• Cam Type: Hydraulic Roller, Cast Core

Included Components

• 1x Hydraulic roller camshaft (113400)

Product Description

The COMP Cams 113400 is a high-performance hydraulic roller cam from the Xtreme Energy series, engineered for GM 2.2 L Ecotec engines from 2000-2010 depending on the platform. Its aggressive lobe profiles and wide RPM range provide strong top-end power and improved throttle response for street and strip applications.

With advertised durations of 264° intake / 268° exhaust and .050" durations of 222° / 224°, this cam enhances mid-range torque and overall engine efficiency. It increases intake vacuum, improving power brake performance while maximizing the benefits of supporting modifications such as headers, intake manifolds, and ECU tuning.

Designed for direct replacement of stock camshafts, the 113400 hydraulic roller cam balances high performance with reliable street drivability. Installation is recommended with proper supporting upgrades and tuning to achieve the full potential of this camshaft in your GM 2.2 L Ecotec engine.
