FOX 213-01-238-A Shaft Eyelet Replacement 5/8" for 2.0 Shocks

Compatible Applications

• Universal - replacement/rebuild component for FOX 2.0 Factory Series coilover, bypass, or smoothie shocks with a 5/8" shaft
• Not a vehicle-specific part; confirm compatibility with your specific shock model and shaft diameter before ordering

Fitment Notes

• For 2.0" body shocks only
• Accepts a -8 heim joint (1/2" uniball)
• Sold individually - one eyelet per unit

Features

• Black anodized 6061-T6 billet aluminum construction for strength and corrosion resistance
• 5/8-18 female threads sized for 5/8" shaft shocks
• Precision-machined to exact FOX Factory Series specifications for a proper rebuild fit
• Allows shock rebuilding or eyelet replacement without purchasing a complete new shock

Specifications

• Type: Shaft Eyelet, Replacement/Rebuild Component
• Compatible Shaft Size: 5/8"
• Thread: 5/8-18
• Width: .900"
• Total Length (TLG): 4.488"
• Outer Diameter: 1.975"
• Inner Diameter: .9995"
• Heim Size: -8 Heim (1/2" Uniball)
• Finish: Black Anodized (Type II)
• Material: 6061-T6 Billet Aluminum

Included Components

• 1x Shaft Eyelet

Product Description

The FOX 213-01-238-A is a direct-replacement shaft eyelet for FOX's 2.0 Factory Series coilover, bypass, and smoothie shocks running a 5/8" shaft, giving builders and rebuilders a way to repair or reconfigure a shock's mounting geometry without buying a whole new unit. Machined from black anodized 6061-T6 billet aluminum, it's built to the same precision standards as FOX's original equipment components.

This eyelet accepts a -8 heim joint (1/2" uniball), making it a common choice for off-road race builds, rock crawlers, and custom suspension setups where mounting length and geometry need to be dialed in precisely. Since it's sold individually and is compatible only with 5/8" shaft, 2.0" body shocks, confirm your exact shock specifications before ordering to ensure proper fitment.
